OPERATION
AND MAINTENANCE MANUAL
Fire damper
type mcr FID S/... c/P
Version FID C 19.11.27.9
FIRE VENTILATION SYSTEMS DEPARTMENT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the mcr FID S c/P Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for mercor mcr FID S c/P Series

Summary of Contents for mercor mcr FID S c/P Series

  • Page 1 Ul. Grzegorza z Sanoka 2 80 – 408 Gdańsk tel. (0-58) 341 42 45 tel./fax (0-58) 341 39 85 OPERATION AND MAINTENANCE MANUAL Fire damper type mcr FID S/… c/P Version FID C 19.11.27.9 FIRE VENTILATION SYSTEMS DEPARTMENT...

  • Page 2: Table Of Contents

    7. TRANSPORT AND STORAGE CONDITIONS ....................... 16 8. MAINTENANCE AND SERVICE ..........................16 9. WARRANTY CONDITIONS ............................ 16 Labelling used in the operation and maintenance manual Option available Option unavailable 2/18 „MERCOR” SA – The company reserves the right to modify and change the document...

  • Page 3: Introduction

    The shut-off partition of dampers is made of a non-flammable plate and is set in a sheet reinforcement profile. On the enclosure, in the 3/18 „MERCOR” SA – The company reserves the right to modify and change the document...
  • Page 4 Such an action may cause damage of the devices' self-braking drive mechanism and is not covered by the warranty. It is recommended that the fire damper were opened and closed when the ventilation system is turned off. 4/18 „MERCOR” SA – The company reserves the right to modify and change the document...
  • Page 5 * embedding border mcr FID S/… c/P fire damper with RST mechanizm RST/KW1 130 30 * granica wmurowania mcr FID S/… c/P fire damper with RST/KW1 5/18 „MERCOR” SA – The company reserves the right to modify and change the document...

  • Page 6: Device Labelling

    6.2. FIXING HOLE The minimum dimensions of the hole which allows correct installation of a rectangular damper is (B+90)x(H+90) mm. 6/18 „MERCOR” SA – The company reserves the right to modify and change the document...

  • Page 7: Embedding

    In order to ensure the fire resistance of the fire separation element, it is mandatory to observe the border of embedding - the damper rotation axis must not be outside the wall. 7/18 „MERCOR” SA – The company reserves the right to modify and change the document...
  • Page 8 6 – Temperature resistant gasket 7 – A section - embedding border X – wall thickness Installation of the mcr FID S/... c/P damper in masonry and concrete walls 8/18 „MERCOR” SA – The company reserves the right to modify and change the document...
  • Page 9 6 – Temperature resistant gasket 7 – A section - embedding border X – Wall thickness Installation of a FID S/... c/P damper in a ceiling 9/18 „MERCOR” SA – The company reserves the right to modify and change the document...
  • Page 10 Other configurations of the mcr FID S /... c/P dampers modules can be made, consisting of two or more dampers, while maintaining the minimum distances between the dampers according to the drawing above. 10/18 „MERCOR” SA – The company reserves the right to modify and change the document...

  • Page 11: Electrical Connections

    Technical specifications - BEE24, BEN24, BEE230 BEN230 Actuators BEE24-ST BEN24-ST Power supply AC 24V 50/60Hz AC 220-240V 50/60 Hz AC 24V 50/60Hz AC 220-240V 50/60 Hz 11/18 „MERCOR” SA – The company reserves the right to modify and change the document...
  • Page 12 - spring ~ 62 dB (A) ~ 67 dB (A) ~ 67 dB (A) ~ 62 dB (A) Connection diagram for the BF24-Tand BF230-T actuators 12/18 „MERCOR” SA – The company reserves the right to modify and change the document...
  • Page 13 Connection diagram for the BFL24-T, BFL230-T, BFN24-T, BFN230-T, BF24-TN and BF230-TN actuators Connection diagram for the BE24, BLE24, BE230 and BLE230 actuators Connection diagram for the BEE24, BEN24, BEE230 and BEN230 actuators 13/18 „MERCOR” SA – The company reserves the right to modify and change the document...
  • Page 14 24 V – 48 V DC 230V AC 230V AC Power consumption 3.5 W 1.6 W 4.5 W 2.5 W Holding force 12 daN 12 daN 12 daN 12 daN 14/18 „MERCOR” SA – The company reserves the right to modify and change the document...
  • Page 15 We put the fuse cells on hooks attached to the damper body and to the partition.   We draw in and lock the hook on the damper body by tightening the nut. 15/18 „MERCOR” SA – The company reserves the right to modify and change the document...

  • Page 16: Transport And Storage Conditions

    8. MAINTENANCE AND SERVICE „Mercor” SA devices should undergo periodical technical inspections and maintenance actions, no less frequent than 12 months during the entire operation period, that is during the warranty period and after it. Inspections and maintenance should be carried out by the manufacturer or by companies that have authorisation for servicing of „MERCOR”...

  • Page 17: Warranty Conditions

    In the matters related with technical inspections, maintenance and the device service, contact the representatives of the Service Department of „Mercor” SA serwis@mercor.com.pl, tel. 058/ 341 42 45 internal 170 or fax 058/ 341 39 85 from 8 AM to 8 PM (Mon - Fri).
  • Page 18 13. Any circumstances listed in Item 10 will relieve “MERCOR” SA from the obligation of surety. The relevant provisions of the Polish Civil Code shall apply to all matters not regulated in these Warranty Terms & Conditions.
