- Page 1 Ul. Grzegorza z Sanoka 2, 80-408 Gdańsk Phone (0-58) 341 42 45 OPERATION AND MAINTENANCE MANUAL (OMM) mcr WIP fire damper Rev. WIP 18.11.14.15 FIRE VENTILATION SYSTEMS DEPARTMENT...
-
Page 2: Table Of Contents
8. MAINTENANCE AND SERVICE (REPAIRS) ......................16 9. WARRANTY TERMS AND CONDITIONS ......................16 Markings used in the OMM Option available Option unavailable (except the CE marking) 2/15 “MERCOR” S.A. – the Company reserves the right to make modifications and changes. -
Page 3: Introduction
In the case of a round duct, a square fire damper is manufactured and equipped with a circular flanged connection or a spigot is used. 3/15 “MERCOR” S.A. – the Company reserves the right to make modifications and changes. - Page 4 It is recommended that the fire damper were opened and closed when the ventilation system is turned off. 4/15 “MERCOR” S.A. – the Company reserves the right to make modifications and changes.
-
Page 5: Manufacturer's Designation Of The Fire Damper
(multiple damper sets) The mcr WIP type fire dampers may also be installed in space dividing elements in buildings that have a lower fire- 5/15 “MERCOR” S.A. – the Company reserves the right to make modifications and changes. -
Page 6: Pre-Installation Inspection
Additionally, the filled space should be sealed with an appropriate mixture or mastic having fire-resistance required by the wall. In order to ensure fire-resistance of a fire damper, the depth to which it can be built in should never be 6/15 “MERCOR” S.A. – the Company reserves the right to make modifications and changes. - Page 7 6. Heat-resistant seal; X – wall thickness 2. ST4.2x16 sheet metal screw 4. E.g. cement mortar Installation of the mcr WIP in concrete masonry unit or brickwork (with full bricks) walls 7/15 “MERCOR” S.A. – the Company reserves the right to make modifications and changes.
- Page 8 A modular protective grid may be supplied by the manufacturer of the fire damper or made by the person installing the product, provided that the following requirements are met: 8/15 “MERCOR” S.A. – the Company reserves the right to make modifications and changes.
-
Page 9: Electrical Connections
Partition closed – actuator indication 0˚ - Belimo BF series - Belimo BE series Partition open – actuator indication 0˚ - Belimo BLE series Partition closed – actuator indication 90˚ 9/15 “MERCOR” S.A. – the Company reserves the right to make modifications and changes. - Page 10 - 30 ...+50C - 30 ...+50C Sound pressure level: – motor max 62 dB (A) max 62 dB (A) max 62 dB (A) max 62 dB (A) 10/15 “MERCOR” S.A. – the Company reserves the right to make modifications and changes.
- Page 11 Notice: 24 V connection through a safety transformer. Several actuators may be connected in parallel. Power consumption should be monitored. Wiring diagram for BFL24-T, BFL230-T, BFN24-T and BFN230-T actuators 11/15 “MERCOR” S.A. – the Company reserves the right to make modifications and changes.
- Page 12 −20 ...+50°C −20 ...+50°C Wiring diagram for EXBF actuators Caution: For proper operation of a device equipped with electrical actuators, it is recommended that the rated voltage 12/15 “MERCOR” S.A. – the Company reserves the right to make modifications and changes.
-
Page 13: Transport And Storage Conditions
Do not move a fire damper by its connection cable or place it in such a way that its weight is supported on the release and control mechanism. Fire dampers cannot be hit or dropped. When moving and 13/15 “MERCOR” S.A. – the Company reserves the right to make modifications and changes. -
Page 14: Maintenance And Service (Repairs)
21 days from the receipt of a written complaint and a proof of purchase or agreement, subject to item 6. „MERCOR” S.A. reserves the right to extend the repair time in the case of complex repairs or those necessitating a purchase of non-standard components or spare parts. - Page 15 11. In the cases referred to in item 10, the liability of „MERCOR” S.A. under statutory warranty is also excluded. 12. The condition for removal of defects is the complaining party’s making available full access to the products in...
