- Page 1 „MERCOR” S.A. ul. Grzegorza z Sanoka 2 80-408 Gdańsk, PL tel. (+48 58) 341 42 45 tel./fax (0-58) 341 39 85 TECHNICAL MANUAL Fire damper type mcr WIP PRO Version WIP PRO 19.11.27.11 FIRE VENTILATION SYSTEMS...
-
Page 2: Table Of Contents
7. TRANSPORT & STORAGE CONDITIONS ......................18 8. MAINTENANCE & SERVICING ..........................18 9. WARRANTY TERMS & CONDITIONS ......................... 19 Technical Manual designations Option available Option unavailable „ 2/25 MERCOR” S.A. – All rights reserved to modifications without prior notice... -
Page 3: Introduction
110 to 1250 mm Length 135 mm Rotation axis Horizontal Horizontal/ vertical Vertical Max. surface area 1,125 m 1,125 m 1,56 m Min. surface are 0,029m „ 3/25 MERCOR” S.A. – All rights reserved to modifications without prior notice... -
Page 4: Design & Operating Principle
Never pull directly on the damper blade to open or close the device. This may result in damage of the self-locking driving gear of the damper, and is not covered by warranty. „ 4/25 MERCOR” S.A. – All rights reserved to modifications without prior notice... - Page 5 /V-M Spring gear: RST/KW1/S RST/KW1/24P RST/KW1/24I RST/KW1/230P RST/KW1/230I Basic dimensions _________________________________________________________________ Fire dapmer mcr WIP PRO with electric actuator BELIMO. Mechanizm BF, BLF, BFL, BFN, BE, wzór „ 5/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
-
Page 6: Device Identification
*Dampers mounted in the floor slabs, may have a maximum dimension BxH: 1000x1000mm Additionally, the fire dampers can be installed: outside of walls in dampers sets (multiple damper sets) „ 6/25 MERCOR” S.A. – All rights reserved to modifications without prior notice... -
Page 7: Pre-Assembly Inspection
In case of installing damper in solid wall – filling the installing gaps with mortar should start from the lowest part of damper, later proceed upward in a way, that will avoid mechanical stress on the trigger control gear guard box with the Y shield. „ 7/25 MERCOR” S.A. – All rights reserved to modifications without prior notice... - Page 8 It is impossible to close the damper, when gaskets are swollen. After installation, carefully clean the fire damper and make sure that there is no debris which could obstruct proper performance of the device. „ 8/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
- Page 9 Fig. mcr WIP PRO fire damper installation example in solid walls made of bricks or stone blocks with a minimum fire resistance rating of EI120. Installation gap: 10 mm. 9/25 „ MERCOR” S.A. – All rights reserved to modifications without prior notice...
- Page 10 7 - Plasterboard rim, 100x12.5 mm Fig. Installation example of the mcr WIP PRO fire damper in a drywall structure with a minimum fire resistance rating of EI120. Installation gap: 10 mm. „ 10/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
- Page 11 Fig. Installation example of the mcr WIP PRO fire damper in a drywall structure with a minimum fire resistance rating of EI120 with masking grid and duct. Installation gap: 10 mm. „ 11/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
- Page 12 Fig. Installation example of the mcr WIP PRO fire damper in a drywall structure with a minimum fire resistance rating of EI120 with masking grid. Installation gap: 10 mm. „ 12/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
- Page 13 WIP PRO fire flap classification. „ 13/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
- Page 14 2 - Concrete floor slab, min. thickness: 150 mm 5 - Thermal trigger (installed in the 7- Plasterboard rims, 100 mm x 12.5 mm 3 – Mounting Z-bars duct 100 mm from the fire damper) „ 14/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
- Page 15 If the installation opening (A) is prepares in rectangle shape, extend the Z3 Z-bars by 120 mm in relation to the dimensions given in the figure below. „ 15/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
- Page 16 Fig. Mounting Z-bars, installation of the mcr WIP PRO fire damper in a concrete ceiling slab with min. thickness: 150 mm, min. fire resistance rating: R120 „ 16/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
- Page 17 Other configurations of the mcr WIP PRO/ … dampers modules can be made, consisting of two or more dampers, while maintaining the minimum distances between the dampers according to the drawing above „ 17/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
- Page 18 ST 3,5x13mm made of galvanized steel according to DIN 7504. The assembly is possible to the steel frame of the damper in distances shown below: Rys. Installation of ventilation ducts. „ 18/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
-
Page 19: Electrical Connections
- 30 ...+50°C - 30 ...+50°C Sound pressure level: - motor max 62 dB (A) max 62 dB (A) max 62 dB (A) max 62 dB (A) „ 19/25 MERCOR” S.A. – All rights reserved to modifications without prior notice... - Page 20 43 dB max 55 dB (A) max 55 dB (A) - spring ~ 62 dB (A) ~ 67 dB (A) ~ 67 dB (A) ~ 62 dB (A) „ 20/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
- Page 21 Connection diagram for the BF24-Tand BF230-T actuators Connection diagram for the BFL24-T, BFL230-T, BFN24-T, BFN230-T, BF24-TN and BF230-TN actuators Connection diagram for the BE24, BLE24, BE230 and BLE230 actuators „ 21/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
- Page 22 - motor 150 s 150 s - return spring 20s 20s Ambient temperature - 20 ...+50°C - 20 ...+50°C Thermal trigger EX zone EEx-e rated installation box „ 22/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
- Page 23 The proper performance of the device with electric actuators requires the rated supply voltage of 24 V ±2% or 230 V ±2%, as applicable. Other voltage values may cause operating malfunctions, that are not covered by the product warranty. „ 23/25 MERCOR” S.A. – All rights reserved to modifications without prior notice...
-
Page 24: Transport & Storage Conditions
Refer all matters related to technical inspection, maintenance and servicing of this equipment to the Mercor S.A. Service Department, serwis@mercor.com.pl, tel. +48 58 341 42 45 ext. 170, fax: +48 58 341 39 85, from 8 AM to 4 PM (Mo-Fri). 9. WARRANTY TERMS & CONDITIONS ______________________________ “MERCOR”... - Page 25 Periodic technical inspection and/or maintenance is not carried out per schedule and/or is carried out by unauthorised personnel or service providers not authorised to do so by “MERCOR” SA and/or the equipment has not been properly operated. Unauthorised personnel attempts any intervention in the product outside of the normal operation and ...
