Smith & Noble Smart Shades Operating & Programming Manual

Rechargeable motorized wood blinds
Hide thumbs Also See for Smart Shades:

Advertisement

Table of Contents

Smith & Noble
Smart Shades
Operati ng & Programming Guide For
Rechargeable Motorized Blinds
Wood Blinds

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart Shades and is the answer not in the manual?

Questions and answers

Related Manuals for Smith & Noble Smart Shades

Summary of Contents for Smith & Noble Smart Shades

  • Page 1 Smith & Noble Smart Shades Operati ng & Programming Guide For Rechargeable Motorized Blinds Wood Blinds...
  • Page 2 Everything You Need A Smooth Set-Up Your remote should come pre-programmed to your blind. The following instructions are to be We want you to love your new blinds and that includes having used if your remote needs to be re-programmed. a smooth installation experience.

  • Page 3: Table Of Contents

    PAIRING THE REMOTE Your blinds will need to be paired to the remote prior to operati ng your blinds. See Pair the Remote below. CHANNEL Table of Contents DISPLAY Pair The Remote This remote control has 15 channels. Before Pair Remote ........... . 2 pairing the remote, determine which blind(s) STOP/ FAVORITES...

  • Page 4: Setti Ng Blinds Limits

    OPERATING THE REMOTE SETTING BLIND LIMITS Remove Plasti c from Batt ery Adjust Blind Limits (If Desired) The lower and upper limits have been set at Before operating the remote, remove the CHANNEL the factory. If you need to make adjustments plasti c in back of remote to engage batt ery.

  • Page 5: Seconds. The Blind Will Jog Once And Sound A

    SETTING BLIND LIMITS SETTING & USING A FAVORITE POSITION Lower Limit If there is only a single blind on the channel proceed to SETTING A FAVORITE 1. Press and hold DOWN and STOP buttons POSITION below. for 5 seconds. The blind will jog once and CHANNEL CHANNEL sound a long beep.
  • Page 6 UNPAIR THE REMOTE ADD OR REMOVE REMOTE OR CHANNEL 1. Press SETTING Butt on (P1) on the motor for Adding a remote 2 seconds. The blind will jog once and sound a long beep. CHANNEL CHANNEL Start with a remote that is already paired to DISPLAY DISPLAY 2.
  • Page 7 ADJUSTING THE JOG FUNCTION SWITCHING DIRECTION / ADJUSTING SPEED Switching Direction (Polarity) When the jog function is activated, tapping the UP or DOWN buttons for less than 2 seconds If the blind goes up when pressing the CHANNEL CHANNEL DOWN button and down when pressing will move the blind is short ‘jogs’...

  • Page 8: Resetting Factory Mode

    RESETTING FACTORY MODE RESETTING FACTORY LIMITS Resetti ng to Factory Mode Upper Limit 1. Press the UP butt on to move the shade to BATTERY WARINING: RESETTING TO FACTORY MODE WILL UNPAIR ALL PREVIOUSLY PAIRED the desired upper positi on. BLIND MOTOR CONTROLLERS AND WILL ERASE ALL PREVIOUSLY SET LIMITS.

  • Page 9: Replacing Batt Ery In Remote

    CHARGING BLIND SOLAR PANEL (OPTIONAL) Determine Solar Panel Placement When the blind begins to operate slower CHARGER The solar panel should be placed where than normal and beeps when operated it is gets the maximum amount of sunlight is ti me to charge the batt ery. per day.

  • Page 10: Install Solar Panel (Opti Onal)

    INSTALL SOLAR PANEL INSTALL SOLAR PANEL Bracket Method Tape Method SOLAR PANEL RECHARGE UNIT Connect the sliding bracket and the L-shape Choose the locati on to mount the solar bracket using the two screws and nuts. Do panel. not overti ghten to allow for easy adjustment Clean the ends of the solar panel where the DOUBLE SIDED TAPE to the solar panel mounti ng height if needed.

  • Page 11: Remove Blind

    CONNECT SOLAR PANEL TO MOTOR SHORTCUTS Connect Solar Panel to Motor SETTINGS STEPS USB CABLE CHARGE PORT BRACKET Before the blind is installed, plug the SETTING button (P1) for 2 seconds (1 jog & 1 beep) → STOP for Pairing Remote solar panel into the side battery port 2 seconds (2 jogs &...

  • Page 12: Troubleshooting

    SAFETY TROUBLESHOOTING Safety First. Style Second To None. ® Great style should never come at the cost of safety. Every Smith & Noble window treatment PROBLEM SOLUTION conforms strictly to today’s safety standards, including permanent tie-down devices and Your brackets may be mounted too close built-in cord stops.

  • Page 13: Warranty

    Warranty Service The enjoyment of your window coverings should be everlasting, which is why our products come with a limited lifetime warranty. The warranty applies to the original owner, requires a proof of purchase (hang on to your receipt!) and covers defects in material or craftsmanship.
