Getting Started; Unpacking; Verifying The Contents Of Your Shipment; Setting Up And Configuring The Sc5511A - SIGNALCORE SC5511A Operating & Programming Manual

G
E T T I N G

Unpacking

All SignalCore products ship in antistatic packaging (bags) to prevent damage from electrostatic
discharge (ESD). Under certain conditions, an ESD event can instantly and permanently damage several
of the components found in SignalCore products. Therefore, to avoid damage when handling any
SignalCore hardware, you must take the following precautions:
•
Ground yourself using a grounding strap or by touching a grounded metal object.
•
Touch the antistatic bag to a grounded metal object before removing the hardware
from its packaging.
!
•
Never touch exposed signal pins. Due to the inherent performance degradation
caused by ESD protection circuits in the RF path, the device has minimal ESD
protection against direct injection of ESD into the RF signal pins.
•
When not in use, store all SignalCore products in their original antistatic bags.
Remove the product from its packaging and inspect it for loose components or any signs of damage.
Notify SignalCore immediately if the product appears damaged in any way.

Verifying the Contents of your Shipment

Verify that your SC5511A kit contains the following items:
Quantity Item
1 SC5511A 20 GHz Signal Source
1 Software Installation USB Flash Drive (may be combined with other products onto a single drive)

Setting Up and Configuring the SC5511A

Figure 1 Front view of the SC5511A showing user I/O locations
SC5511A User Manual
S
T A R T E D
Rev 1.7.0 4
