SIGNALCORE SC5511A Operating & Programming Manual page 24

Table 26 Register 0x15 RF_ALC_MODE (1 Byte)
Bit Type
[0] WO RF1 ALC mode
[7:1] WO Unused
Table 27 Register 0x16 RF_STANDBY (1 Byte)
Bit Type
[0] WO RF1 standby
[7:1] WO Unused
Table 28. Register 0x17 REFERENCE_MODE (1 Byte)
Bit Type
[0] WO Lock to external
reference source
[1] WO Reference out select
[7:2] WO Unused
Table 29 Register 0x18 REFRENCE_DAC_VALUE (2 Bytes)
Bit Type
[13:0] WO DAC Value
[15:14] WO Unused
Table 30 Register 0x18 ALC_DAC_VALUE (2 Bytes)
Bit Type
[13:0] WO DAC Value
[15:14] WO Unused
Table 31. Register 0x01A Reserved (1 Byte)
Bit Type
[7:0] WO Reserved
Table 32 Register 0x1B STORE_DEFAULT_STATE (1 Byte)
Bit Type
SC5511A User Manual
Name
Name
Name
Name
Name
Name
Name Width
Width
1 0 = Amplitude is corrected using ALC closed loop
1 = Amplitude is corrected opened loop.
7 Set all bits to 0
Width
1 1 = puts the RF1 channel into standby. Standby
powers down all circuitry associated with ch1,
thus reducing power consumption.
7 Set all bits to 0.
Width
1 1 = instructs the device to lock to external source.
No attempt will be made unless a reference
source is detected.
1 0 = Outputs a 10 MHz signal
1 = Outputs a 100 MHz signal
6 Set all bits to 0.
Width
14 14 bit word to set/adjust the internal 10 MHz
TCXO frequency.
2 Set all bits to 0.
Width
14 14 bit word to set/adjust the ALC DAC value. This
is useful to make output adjustment. The current
ALC DAC value can be read back via register 0x25
2 Set all bits to 0.
Width
7
Rev 1.7.0
Description
Description
Description
Description
Description
Description
Description
20
