SIGNALCORE SC5511A Operating & Programming Manual page 27

[7:4] WO Unused
[39:0] RO Data
Table 40. Register 0x21 GET_TEMPERATURE (1 byte, 5 Bytes)
Bit Type
[7:0] WO Unused
[39:8] RO Valid flatten float type
temperature
[7:0] WO Invalid data
Table 41. Register 0x22 DEVICE_STATUS (1 Byte, 5 Bytes)
Bit Typ
e
[7:0] WO Unused
[39] RO List Config: Trig Out
Mode
[38] RO List Config: Trig Out
Enable
[37] RO List Config: Return to
Start
[36] RO List Config: Step Trig
[35] RO List Config: HW Trig
[34] RO List Config: Waveform
(Tri/Saw)
[33] RO List Config: Sweep Dir
[32] RO List Config: SSS mode
[31:30] RO Reserved
[29] RO Operate: Over Temp
[28] RO Operate: RF1_mode
[27] RO Operate: list running
[26] RO Operate: ref_out_select
[25] RO Operate: ext_ref_detect
[24] RO Operate: ext_ref_lock
[23] RO Operate: RF1_enable
SC5511A User Manual
Name Width
Name Width
Rev 1.7.0
float phase=*(float*)&read_in_unsigned_int
4 Set all bits to 0.
40 Data with varying sizes of unsigned type.
8 Set all to 0
32 The data is returned in unsigned integer form of
flatten float type. To recast the unsigned integer
back to float use:
float temp = *(float*)&read_in_unsigned_int_var
8 zeros
8 Set all bits to 0. Sets up the read-back buffer with
contents of the current device status. Contents
are immediately available for USB read. The
contents occupy effectively the lower two bytes.
In the case of SPI, contents are transferred to the
serial output buffer, so a second query to the
SERIAL_OUT_BUFFER register is required to
transfer its contents and also to clear the output
buffer.
1
1
1
1
1
1
1
1
2
1 Device temperature above threshold of ~ 75
1 0 = fix, 1 = list/sweep
1 1 = device triggered and running list/sweep mode
1 0 = 10 MHz, 1 = 100 MHz
1 1 = reference source at ref port
1 1 = lock to external sources is enabled
1 1 = RF1 output is enabled
