SIGNALCORE SC5511A Operating & Programming Manual page 25

[7:0] WO Reserved
Table 33. Register 0x01C Reserved (1 Byte)
Bit Type
[7:0] WO Reserved
Table 34. Register 0x01D Reserved (1 Byte)
Bit Type
[7:0] WO Reserved
Table 35. Register 0x01E RF2_STANDBY(1 Byte)
Bit Type
[0] WO RF2 standby
[7:1] WO Unused
Table 36. Register 0x01F RF2_FREQUENCY (2 Bytes)
Bit Type
[14:0] WO Frequency (MHz)
Table 377. Register 0x47 SYNTH_SELF_CAL (1 Byte)
Bit Type
[7:0] WO Unused
SC5511A User Manual
8 Set all bits to 0. Calling this register will store the current
configuration into memory. On reset or power-up these
values are read from memory and set as the default
values. Some of the values are:
➢ RF1 parameters
➢ List mode configuration
➢ RF mode
➢ List mode parameters
Name Width
Name Width
Name Width
Name Width
Name Width
Rev 1.7.0
7
7
1 1 = puts the RF2 channel into standby. Standby
powers down all circuitry associated with ch2,
thus reducing power consumption.
7 Set all bits to 0.
14 Frequency word in MHz; 25 to 3000
8 Set all bits to 0.
➢ RF2 parameters
Description
Description
Description
Description
Description
21
