[5] WO Return to Start
[6] WO Trigger Output
[7] WO Trigger Out Mode
Table 11. Register 0x06 LIST_START_FREQ (5 Byte)
Bit Type
[39:0] WO List Start Frequency
Table 12. Register 0x07 LIST_STOP_FREQ (5 Bytes)
Bit Type
[39:0] WO List Stop Frequency
Table 13. Register 0x08 LIST_STEP_FREQ (5 Bytes)
Bit Type
[39:0] WO List Step Frequency
Table 14. Register 0x09 LIST_DWELL_TIME (4 Bytes)
Bit Type
[31:0] WO List Dwell Time
SC5511A User Manual
Name Width
Name Width
Name Width
Name Width
Rev 1.7.0
1 0 = Stop at end of sweep/list. The frequency will
stop at the last point of the sweep/list.
1 = Return to start. The frequency will return and
stop at the beginning point of the sweep or list
after a cycle.
1 0 = No trigger output.
1 = Puts a trigger pulse on the TRIGOUT pin
1 0 = Puts out a trigger pulse at each frequency
change, right after all internal devices are
configured.
1 = Puts out a trigger pulse at the completion of
each sweep/list cycle.
40 Sets the start frequency for a sweep. Start
frequency should always be lower than the stop
frequency. The Sweep Direction bit [1] of register
0x05 should be used to determine where the
sweep should begin.
40 Sets the stop frequency for a sweep. Stop
frequency should always be greater than the start
frequency. The Sweep Direction bit [1] of register
0x05 should be used to determine where the
sweep should begin.
40 Sets the step frequency for a sweep. Step size
should not exceed the difference between the
start and stop frequencies.
32 Set the dwell time at each step frequency. The
Dwell time is incremented in 500 s increments.
For example, to produce a 10 ms dwell time the
value written to this register is 20d.
Description
Description
Description
Description
