7.5 Lubricating

Proper lubrication will prevent seizures and rust, and ensure smooth oper-
ation. Lubricate every 6 mouths.
Lubricate the illustrated points.
No.
1
2
3
4
5
6
7
8
1
2
3
*Reference: To lubricate the roller shaft, remove the outside nut, tighten the furnished grease fitting with a
spanner, and apply grease to the rollers through the grease fitting. After greasing, remove the
grease fitting, and tighten the nut firmly to the shaft.
Maintenance
One-way dump
Lubrication area
Parking brake pedal link section
Clutch lever pivot
Hydraulic cylinder pivot • (Slewing ring)
Swing roller pivot
Roller shaft*
Upper roller
Idler
Bessel pivot
Throttle lever pivot
Hydraulic V-belt tension arm
Dumper lever pivot
Lubrication
points
1
2
2 (7)
2
10
2
2
1
1
1
1
