ADLINK Technology NuPRO-E72 User Manual

Picmg 1.3 full size lga1150 intel xeon e3-1200v3 processor-based shb
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
PICMG
1.3 Full Size LGA1150 Intel
1200v3 Processor-Based SHB
Manual Rev.:
Revision Date:
Part No:
Advance Technologies; Automate the World.
NuPRO-E72
User's Manual
2.05
Apr. 24, 2015
50-13074-1010
®
®
Xeon
E3-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NuPRO-E72 and is the answer not in the manual?

Questions and answers

Related Manuals for ADLINK Technology NuPRO-E72

Summary of Contents for ADLINK Technology NuPRO-E72

  • Page 1 NuPRO-E72 ® ® ® PICMG 1.3 Full Size LGA1150 Intel Xeon 1200v3 Processor-Based SHB User’s Manual Manual Rev.: 2.05 Revision Date: Apr. 24, 2015 Part No: 50-13074-1010 Advance Technologies; Automate the World.
  • Page 2 Revision History Revision Release Date Description of Change(s) 2.00 2014/9/30 Initial release 2.05 2015/4/24 Procedural errata rectified...

  • Page 3: Preface

    NuPRO-E72 Preface Copyright 2015 ADLINK Technology, Inc. This document contains proprietary information protected by copy- right. All rights are reserved. No part of this manual may be repro- duced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
  • Page 4 Conventions Take note of the following conventions used throughout this manual to make sure that users perform certain tasks and instructions properly. Additional information, aids, and tips that help users perform tasks. NOTE: NOTE: Information to prevent minor physical injury, component dam- age, data loss, and/or program corruption when trying to com- plete a task.

  • Page 5: Table Of Contents

    NuPRO-E72 Table of Contents Revision History..............ii Preface ..................iii List of Figures ................ ix List of Tables................xi 1 Introduction ................ 1 Overview................1 Features................1 Specifications............... 2 Block Diagram ..............4 Functional Description ............4 Mechanical Drawing ............7 I/O Connectivity ..............
  • Page 6 Installing Memory Modules ..........27 Jumpers & Switches ............29 Driver Installation ............... 31 2.6.1 Installing Chipset Driver..........32 2.6.2 Installing Graphics Driver......... 32 2.6.3 Installing Ethernet Driver .......... 32 2.6.4 Installing Management Engine Driver....... 32 2.6.5 Installing USB 3.0 Driver........... 32 A Appendix: BIOS Setup............35 Starting the BIOS ...............
  • Page 7 NuPRO-E72 B Appendix: Watchdog Timer..........71 Sample Code ..............71 C Appendix: System Resources.......... 75 System Memory Map............75 Direct Memory Access Channels........75 IO Map ................76 Interrupt Request (IRQ) Lines..........77 Important Safety Instructions ..........83 Getting Service..............85...
  • Page 8 This page intentionally left blank. viii Table of Contents...

  • Page 9: List Of Figures

    NuPRO-E72 List of Figures Figure 1-1: NuPRO-E72 Block Diagram ..........4 Figure 1-2: NuPRO-E72 Board ............7 Figure 1-3: Rear I/O Panel .............. 13 Figure 1-4: NuPRO -E72 Board Topography ........16 List of Figures...
  • Page 10 This page intentionally left blank. List of Figures...

  • Page 11: List Of Tables

    NuPRO-E72 List of Tables Table 1-1: NuPRO-E72 I/O Connectivity .......... 8 Table C-1: System Memory Map............. 75 Table C-2: Direct Memory Access Channels........75 Table C-3: IO Map ................76 Table C-4: IRQ Lines PIC Mode............77 Table C-5: IRQ Lines APIC Mode ........... 79 Table C-6: PCI Configuration Space Map ........
  • Page 12 This page intentionally left blank. List of Tables...

  • Page 13: Introduction

    DDR3 ECC memory is supported up to a maximum of 16 GB in two DIMM slots. These advanced features, coupled with PCI Express® x16 expan- sion capability, dual PCI Express®-based Gigabit Ethernet, SATA 6 Gb/s and USB 3.0 support make the NuPRO-E72 ideal for vision and automation control applications. 1.2 Features ®...

  • Page 14: Specifications

    To purchase the optional DB-Audio2 daughter board, please contact your ADLINK sales representative. NOTE: NOTE: 1.3 Specifications System ® ® • Intel Xeon E3-1275v3, 3.5GHz, 8M Cache, 22nm, 84W TDP, LGA1150 (4C) ® ® • Intel Xeon E3-1225v3, 3.2GHz, 8M Cache, 22nm, 84W TDP, LGA1150 (4C) ®...
  • Page 15 NuPRO-E72 I/O Interfaces • 6x USB 3.0 ports (2x on rear panel, 4x on SHB) • 4x USB 2.0 on backplane • 4x SATA 6 Gb/s on SHB • 6x serial ports via onboard pin-header (5x RS-232, 1x RS-232/422/485 with auto flow control) •...

  • Page 16: Block Diagram

    Audio Pin header for KB/MS Figure 1-1: NuPRO-E72 Block Diagram 1.5 Functional Description Processor Support The NuPRO-E72 is PICMG 1.3 System Host Board supporting the ® ® 4th Generation Intel Xeon and Core™ processor family in LGA1150 socket. An integrated memory controller supports dual ®...
  • Page 17 PCI-E bus of the C226 PCH. Intel® AMT 9.0 (I217LM on LAN1), Wake-on-LAN and PXE are supported. Serial ATA The NuPRO-E72 provides four Serial ATA ports with data transfer rates of up to 6.0 GB/s. Intel® Rapid Storage Technology supports AHCI and RAID 0/1/5/10 functionality.
  • Page 18 Trusted Platform Module The NuPRO-E72 optionally supports TPM ver. 1.2 (Trusted Plat- form Module) for secure storage of keys, passwords and digital certificates. Systems supporting TPM offer improved hardware-...

  • Page 19: Mechanical Drawing

    NuPRO-E72 1.6 Mechanical Drawing 38.5 4.92 Dimensions 20.59 in mm 123.09 126.39 Figure 1-2: NuPRO-E72 Board Introduction...

  • Page 20: I/O Connectivity

    PCIe x1 PCI Express x16 expansion can be configured as two PCI Express PCIe x16 — — x8 or one PCI Express x8 and two PCI Express PCI 32bit/33MHz — — via TI XIO2001 Table 1-1: NuPRO-E72 I/O Connectivity Introduction...

  • Page 21: Power Consumption

    NuPRO-E72 1.8 Power Consumption 1.8.1 Intel® Xeon® Processor E3-1225 v3 3.2GHz (84W) System Configurations ® ® Intel Xeon Processor E3-1225 v3 (8M Cache, 3.20 GHz) Memory InnoDisk M3U0-8GSSALPC-AC56 8GB DDR3 Slot1 1600 LV DIMM Memory InnoDisk M3U0-8GSSALPC-AC56 8GB DDR3 Slot2 1600 LV DIMM ®...

  • Page 22: (45W)

    System Configurations 0.82/5.03 0.81/5.02 Windows 7 8.09/12.01 103.9666 7.80/12.01 100.3512 (Max loading) 0.81/3.31 0.79/3.30 1.8.2 Intel® Xeon® Processor E3-1268L v3 2.30 GHz (45W) System Configurations ® ® Intel Xeon Processor E3-1268L v3 (8M Cache, 2.30 GHz) Memory InnoDisk M3U0-8GSSALPC-AC56 8GB DDR3 Slot1 1600 LV DIMM Memory...

  • Page 23: Intel® Core™ I3-4330 Processor 3.5Ghz (54W)

    NuPRO-E72 System Configurations 1.15/4.99 1.07/4.99 Windows 7 3.35/12.03 48.679 3.23/12.04 46.8685 (Typical) 0.80/3.30 0.80/3.30 0.80/4.99 0.81/5.00 Windows 7 4.80/12.03 64.376 4.62/11.99 62.1168 (Max loading) 0.80/3.30 0.81/3.30 ® ™ 1.8.3 Intel Core i3-4330 Processor 3.5GHz (54W) System Configurations ® Intel Core™ i3-4330 Processor (4M Cache, 3.50...

  • Page 24: Intel® Celeron® G1820 Processor 2.7Ghz (53W)

    System Configurations 0.64/5.01 0.66/5.01 0.81/12.07 15.6642 0.84/12.07 16.1596 0.81/3.31 0.82/3.31 0.10/5.04 0.504 0.11/5.04 0.5544 0.08/5.04 0.4032 0.08/5.04 0.4032 0.73/4.97 0.58/4.97 Windows 7 0.56/12.07 13.0933 0.76/12.07 14.7288 (Idle) 0.82/3.30 0.81/3.30 1.14/5.00 1.03/5.00 Windows 7 3.22/12.08 47.3366 2.34/12.08 36.1892 (Typical) 0.83/3.30 0.84/3.30 0.79/5.00 0.82/5.00 Windows 7...

  • Page 25: Rear I/O Panel

    NuPRO-E72 System Configurations BIOS EIST/C-state BIOS EIST/C-state Enabled Disabled Item Current (A)/ Power Current (A)/ Power Voltage (V) Voltage (V) 0.63/5.00 0.61/5.00 0.85/12.07 16.0575 0.85/12.07 15.9575 0.80/3.31 0.80/3.31 0.10/5.03 0.503 0.10/5.04 0.503 0.05/4.96 0.248 0.06/4.96 0.2976 0.73/5.00 0.72/5.02 Windows 7 0.59/12.11...
  • Page 26 USB 3.0 Connectors Pin # Signal Name USB3.0_P5VA USB2_CMAN USB2_CMAP USB3A_CMRXN USB3A_CMRXP USB3A_CMTXN USB3A_CMTXP LAN (RJ-45) Ports 10BASE-T/ Pin # 1000BASE-T 100BASE-TX BI_DA+ BI_DA- LED1 LED2 BI_DB+ BI_DC+ BI_DC- BI_DB- BI_DD+ BI_DD- Refer to the table below for the LAN port LED definitions. LED1 LED2 Status...
  • Page 27 NuPRO-E72 VGA Port Pin # Signal Pin # Signal +5 V Green Ground Blue DDC DAT Ground HSYNC Ground VSYNC Ground DDC CLK Ground Introduction...

  • Page 28: Board Layout

    1.10 Board Layout 8 9 10 11 12 13 Figure 1-4: NuPRO -E72 Board Topography Connector Description CN24 ATX 12V Power connector CN28/29 DDR3 ECC DIMM slots CN45 System Panel pin header FAN1 CPU fan connector CN30/32 SATA 6 Gb/s connectors CN31/33 SATA 6 Gb/s connectors CN16...

  • Page 29: Onboard Connectors

    NuPRO-E72 1.11 Onboard Connectors COM1~6 Connector (RS-232) (CN11~14/16/23) Pin # RS-232 Signal COM1 COM2 COM3 COM4 COM5 COM6 Connector CN23 CN16 CN11 CN12 CN13 CN14 Pitch 2.54 mm 2.54 mm 2.00 mm 2.00 mm 2.00 mm 2.00 mm COM1 Connector (RS-422/485) (CN23)
  • Page 30 USB 3.0 Connectors (CN36/37) Pin # Signal Pin # Signal P5V_USB3B S_USB3_RN3_R P5V_USB3B S_USB3_RP3_R S_USB3_RN4_R S_USB3_RP4_R S_USB3_TN3_R S_USB3_TP3_R S_USB3_TN4_R S_USB3_TP4_R S_USB2_N2_R S_USB2_P2_R S_USB2_N3_R S_USB_OC1# S_USB2_P3_R DVI-D Onboard Connector(CN17) Pin # Signal Pin # Signal DVI-Clock+ DVI-Data0- DVI-Clock- DVI-Data0+ DVI-I2C-Clock DVI-Data1- DVI-I2C-Data DVI-Data1+ DVI-HPD...
  • Page 31 NuPRO-E72 DVI-D Bracket Connector (optional cable w/ bracket, P/N 30-01052-2000) Pin # Signal Pin # Signal TMDS Data2- TMDS Data3+ TMDS Data2+ +5 V Power TMDS Data2/4 Shield TMDS Data4- Hot Plug Detect TMDS Data4+ TMDS Data0- DDC Clock [SCL]...
  • Page 32 Serial ATA Connectors (CN30~33) Pin # Signal HD Audio Daughter Board Connector (CN40) This connector is designed for use with the ADLINK DB-Audio2 daughter board. Pin # Signal Function Ground AUD_BCLK Audio Clock Ground ICH_AUD_SDIN1 Audio Data Input + 5V ICH_AUD_SDOUT Audio Data Output P5V_AUD + 5V...
  • Page 33 NuPRO-E72 System Panel Connector (CN45) Connects to chassis-mounted buttons, speakers, and LEDs. Pin # Signal Function Pin Group WDSPK Speaker signal Chassis Speaker Power Ground Key Lock KEYLOCK Keyboard lock PLED Power LED signal Power LED Power LED pull-up Ground...
  • Page 34 This page intentionally left blank. Introduction...

  • Page 35: Getting Started

    2-port COM cable with bracket x2 for COM3-6 (2.0 mm pitch) Driver DVD User’s manual The NuPRO-E72 must be protected from static discharge and physical shock. Never remove any of the socketed parts except at a static-free workstation. Use the anti-static bag shipped with WARNING: the product to handle the board.
  • Page 36 To install the CPU: 1. Press down on the locking arm (A), then push it away from the socket to disengage it from the retention tab (B). 2. Raise the locking arm to unlock the load plate. 3. Lift the load plate to uncover the socket. 4.
  • Page 37 NuPRO-E72 indicator (B). Do not touch socket contacts. WARNING: 5. Hold the CPU using thumb and forefinger as shown. Position the CPU over the socket, matching the notches on the sides of the CPU with the alignment keys on the socket (A).
  • Page 38 Carefully place the CPU into the socket vertically. The socket has cutouts for your fingers to fit into. Cutouts 6. Gently lower the load plate. Make sure the front edge of the plate is under the screw as indicated. 7. Lower the locking arm and fasten it to the retention tab (A). The load plate should be locked underneath the screw as shown (B).

  • Page 39: Installing The Cpu Fan And Heatsink

    SHB labeled FAN2 (See “Board Layout” on page 16.). 2.4 Installing Memory Modules The NuPRO-E72 supports up to 16 GB of DDR3 ECC 1333/1600 MHz memory modules in two DIMM sockets. A DDR3 ECC module has a 240-pin footprint compared to the legacy 184-pin DDR DIMM.
  • Page 40 Memory Configuration Options The NuPRO-E72 supports 1GB, 2GB, 4GB and 8GB unbuffered DDR3 ECC DIMMs in the following configurations: Channel A: DIMM1 Channel B: DIMM2 For dual-channel configuration, the total size of memory module installed per channel must be the same (DIMM1 = DIMM2).

  • Page 41: Jumpers & Switches

    NuPRO-E72 Notch Break 4. Insert the module firmly into the slot until the retaining clips snap back inwards and the module is securely seated. 2.5 Jumpers & Switches Clear CMOS Jumper (JBAT1) To clear the BIOS settings (RTCRTS# asserts): 1. Power down and disconnect power from the system.
  • Page 42 6. Re-short pins 1-2, and power up the system.. CMOS Status Connection JBAT1 Normal 1 – 2 Clear CMOS 2 – 3 Clear RTC Jumper (JBAT2) To clear the BIOS settings and data/time (SRTCRST# and RTCRST# assert): 1. Power down and disconnect power from the system. 2.

  • Page 43: Driver Installation

    NuPRO-E72 COM1 Mode Switch (SW13) DIP #1 DIP #2 COM1 Mode RS-232 RS-422 RS-485 2.6 Driver Installation This chapter provides information on how to install the NuPRO- E72 device drivers under Windows 7 64-bit. The device drivers are located in the following ADLINK All-in-One DVD directories:...

  • Page 44: Installing Chipset Driver

    Installing Chipset Driver ® To install the Intel C226 Express chipset driver, locate the directory X:\NuPRO\NuPRO-E72\Chipset\ on the ADLINK All-in- One DVD, run the program infinst_autol.exe and follow the onscreen instructions. Restart the system if prompted. 2.6.2 Installing Graphics Driver ®...
  • Page 45 NuPRO-E72 2. Run the program setup.exe and follow the onscreen instructions. Restart the system if prompted. Getting Started...
  • Page 46 This page intentionally left blank. Getting Started...

  • Page 47: A Appendix: Bios Setup

    NuPRO-E72 Appendix A BIOS Setup The following chapter describes basic navigation for the AMIBIOS® EFI BIOS setup utility. A.1 Starting the BIOS To enter the setup screen, follow these steps: 1. Power on the motherboard 2. Press the < Delete > key on your keyboard when you see the following text prompt: <...
  • Page 48 Setup Menu The main BIOS setup menu is the first screen that you can navi- gate. Each main BIOS setup menu option is described in this user’s guide. The Main BIOS setup menu screen has two main frames. The left frame displays all the options that can be configured.
  • Page 49 NuPRO-E72 Note: There is a hot key legend located in the right frame on most setup screens. The < F8 > key on your keyboard is the Fail-Safe key. It is not dis- played on the key legend by default. To set the Fail-Safe settings of the BIOS, press the <...
  • Page 50 The < F10 > key allows you to save any changes you have made and exit Setup. Press the < F10 > key to save your changes. The following screen will appear: Press the < Enter > key to save the configuration and exit. You can also use the <...

  • Page 51: Main Setup

    NuPRO-E72 can also allow you to display the setup sub-screens. A.2 Main Setup When you first enter the Setup Utility, you will enter the Main setup screen. You can always return to the Main setup screen by select- ing the Main tab. There are two Main Setup options. They are described in this section.

  • Page 52: Advanced Bios Setup

    Displays the BIOS build data. System Time/System Date Use this option to change the system time and date. Highlight Sys- tem Time or System Date using the < Arrow > keys. Enter new val- ues using the keyboard. Press the < Tab > key or the < Arrow > keys to move between fields.

  • Page 53: Acpi Settings

    NuPRO-E72 The sub menus are described on the following pages. Launch PXE OpROM Boot Option for Legacy Network Devices. Options: Enabled/ Disabled. A.3.1 ACPI Settings Enable APIC Auto Configuration BIOS ACPI Auto Configuration. Options: Enabled/Disabled.
  • Page 54 Enable Hibernation Enable or disable the system's ability to hibernate (S4 sleep state). This option may be not effective with some OS's. ACPI Sleep State Select the highest ACPI sleep state the system will enter, when the SUSPEND button is pressed. Options: S1, S3, Suspend Disable.

  • Page 55: Trusted Computing

    NuPRO-E72 A.3.2 Trusted Computing Trusted computing is an industry standard to make personal com- puters more secure through a dedicated hardware chip, called a Trusted Platform Module (TPM). TPM Support This option enables or disables the TPM support. System reset is required.

  • Page 56: Cpu Configuration

    A.3.3 CPU Configuration Active Processor Cores Number of cores to enable in processor. Options: All, 1, 2. Limit CPUID Value Maximum When Enabled, the processor will limit the maximum CPUID input value to 03h when queried, even if the processor sup- ports a higher CPUID input value.
  • Page 57 NuPRO-E72 tems to software. This allows for multiple, independent operat- ing systems to be running simultaneously on a single system. Power Technology Sets the power management features. Options: Disable, Energy Efficient, Custom. Socket 0 CPU Information...

  • Page 58: Sata Configuration

    A.3.4 SATA Configuration SATA Mode Options: IDE, RAID, AHCI. Serial ATA Controller 0/1 Appears when SATA mode is set to IDE. This item specifies whether Serial ATA Controller 0/1 is initialized in Compatible or Enhanced mode of operation. The settings are Disabled, Com- patible and Enhanced.

  • Page 59: Intel Txt Configuration

    NuPRO-E72 A.3.5 Intel TXT Configuration Intel Trusted Execution Technology (Intel TXT) support can only be enabled when TPM is enabled, if the CPU supports Safer Mode Extensions (SMX), and Intel® Virtualization Technology (Intel® VT) and Intel® Virtualization Technology for Directed I/O (VT-d)

  • Page 60: Intel Igd Swsci Opregion

    A.3.6 Intel IGD SWSCI OpRegion DVMT Mode This item allows the user to enable or disable the DVMT func- tion. DVMT/Fixed Memory Select DVMT/Fixed memory size used by the Integrated Graphics Device. Options: 128MB, 256MB, Maximum. IGD - Boot Type Select the video device which will be activated during POST.

  • Page 61: Usb Configuration

    NuPRO-E72 A.3.7 USB Configuration Legacy USB Support Legacy USB Support refers to USB mouse and keyboard sup- port. Normally if this option is not enabled, any attached USB mouse or USB keyboard will not become available until a USB compatible operating system is fully booted with all USB driv- ers loaded.
  • Page 62 XHCI Hand-Off This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver. Options: Enable, Disable. EHCI Hand-Off This is a workaround for OSes without EHCI hand-off support. The EHCI ownership change should be claimed by EHCI driver.

  • Page 63: Super Io Configuration

    NuPRO-E72 A.3.8 Super IO Configuration Serial Port1-6 Configuration Enter the submenu for each serial port to enable/disable and view the I/O port and IRQ settings. Parallel Port Configuration Enter the submenu to enable/disable the parallel port and specify the base I/O port address.

  • Page 64: Hardware Monitor

    A.3.9 Hardware Monitor You can use this screen to view System Status information and to select options for FAN1 settings (FAN2 is set to Full On by default). Smart Fan 1 Mode Setting Three operating modes are provided for FAN1: Full Mode, Auto- matic Mode, and Manual Mode.

  • Page 65: Amt Configuration

    NuPRO-E72 When the temperature in degrees (°C) is higher than the set value, FAN1 will increase its speed according to the PWM Slope Setting value. Fan Start PWM Sets the PWM value of the fan between Fan Off Temperature Limit and Fan Start Temperature Limit. Minimum value is 0 and maximum is 127.
  • Page 66 Unconfigure AMT/ME This item allows the user to unprovision the AMT/ME function without a password. WatchDog Timer Options: Enabled/Disabled. OS WatchDog Timer Sets the OS WatchDog Timer (seconds). BIOS WatchDog Timer Sets the BIOS WatchDog Timer (seconds).

  • Page 67: Serial Port Console Redirection

    NuPRO-E72 A.3.11 Serial Port Console Redirection COM0/1 Console Redirection Options: Enabled/Disabled. Console Redirection Settings The settings specify how the host computer and the remote computer exchange data. Both computers should have the same or compatible settings.
  • Page 68 Terminal Type This option is used to select either VT100/VT-UTF8 or ANSI terminal type. Options: VT100, VT100+, VT-UTF8, ANSI. Bits per second Select the bits per second you want the serial port to use for console redirection. The options are 115200, 57600, 38400, 19200, 9600.
  • Page 69 NuPRO-E72 Serial Port for Out-of-Band Management These settings control the ACPI serial port redirection table (SPCR) which is used by Windows servers to provide Windows Emergency Management Services (EMS) and is independent from console redirection output. OoB Management or EMS...

  • Page 70: Chipset Setup

    Flow Control Set this option to select Flow Control for console redirection. The settings for this value are None, Hardware RTS/CTS. Data Bits Displays the frame width for Out-of-Band Management. Parity Displays the parity for Out-of-Band Management. Stop Bits Displays the number of stop bits for Out-of-Band Management. A.4 Chipset Setup Select the Chipset tab from the setup screen to enter the Chipset BIOS Setup screen.

  • Page 71: Graphics And Memory Bridge Configuration

    NuPRO-E72 A.4.1 Graphics and Memory Bridge Configuration VT-d Intel Virtualization Technology for Directed I/O. Options: Enabled/ Disabled. Initial Graphics Adapter Allows you to select which graphics controller to use as the pri- mary boot device. Options: IGD, PCI/IGD, PCI/PEG, PEG/IGD, PEG/PCI.

  • Page 72: Pch Bridge Configuration

    A.4.2 PCH Bridge Configuration 82574L LAN Controller Controls the onboard Intel 82574L LAN controller. Options: Enabled/Disabled. Restore on AC Power Loss Determines which state the computer enters when AC power is restored after a power loss. The options for this value are Last State, Power On and Power Off.
  • Page 73 NuPRO-E72 PCI Express Port Configuration PCI Express Port 1~8 Configures the PCI Express ports in of the chipset. Options: Auto, Enable, Disable. PCIe Sub Decode Enable or disable the PCIe Sub Decode port. This option is avail- able when the Subtractive Decode Agent is enable (PCHTrap9[14]) = '1b'.

  • Page 74: Management Engine Subsystem

    A.4.3 Management Engine Subsystem ME Subsystem Options: Enabled/Disabled. ME Temporary Disable Options: Enabled/Disabled (reset required). End of POST Message Options: Enabled/Disabled. Execute MEBx Options: Enabled/Disabled. MEBx Mode Options: Normal, Hidden Ctrl+P, Enter MEBx setup.
  • Page 75 NuPRO-E72 Integrated Clock Chip Configuration ICC Enable Integrated Clock Chip. Options: Enabled/Disabled.

  • Page 76: Boot Configuration

    A.5 Boot Configuration Select the Boot tab from the setup screen to enter the Boot BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Boot Device Priority, to go to the sub menu for that item.
  • Page 77 NuPRO-E72 When it is disabled, the BIOS will display the normal POST messages, instead of the full-screen logo. Gate A20 Active Options: Upon Request, Always. Boot Option Priorities Set the boot device options to determine the sequence in which the computer checks which device to boot from.

  • Page 78: Security Setup

    A.6 Security Setup Password Support Two Levels of Password Protection Provides both a Supervisor and a User password. If you use both passwords, the Supervisor password must be set first. The system can be configured so that all users must enter a password every time the system boots or when Setup is exe- cuted, using either or either the Supervisor password or User password.
  • Page 79 NuPRO-E72 Remember the Password Keep a record of the new password when the password is changed. If you forget the password, you must erase the sys- tem configuration information in NVRAM. To access the sub menu for the following items, select the item and press <...

  • Page 80: Exit Menu

    A.7 Exit Menu Select the Exit tab from the setup screen to enter the Exit BIOS Setup screen. You can display an Exit BIOS Setup option by high- lighting it using the < Arrow > keys. The Exit BIOS Setup screen is shown below.
  • Page 81 NuPRO-E72 Discard Changes and Exit Select this option to quit Setup without making any permanent changes to the system configuration. Discard Changes and Exit Setup Now? [Ok] [Cancel] appears in the window. Select Ok to discard changes and exit. Save Changes and Reset Reset the system after saving the changes.
  • Page 82 the current boot order. If you are booting to the EFI Shell, an exit from the shell returns to Setup.

  • Page 83: B Appendix: Watchdog Timer

    NuPRO-E72 Appendix B - Watchdog Timer A sample program for configuring the NuPRO-E72’s watchdog timer is included on the ADLINK All-in-One DVD in the following directory: \NuPRO\NuPRO-E72\WDT. B.1 Sample Code #include<stdio.h> #include<dos.h> static unsigned int IT8783_ioPort = 0x2e; void Enter_IT8783_Config(unsigned int flag) if(flag) IT8783_ioPort = 0x4e;...
  • Page 84 Get_IT8783_ID(unsigned int &ID1, unsigned int &ID2) outportb(IT8783_ioPort, 0x20); ID1 = inportb(IT8783_ioPort+1); outportb(IT8783_ioPort, 0x21); ID2 = inportb(IT8783_ioPort+1); void IT8783_WDTRun(unsigned int count_value, unsigned int PLEDflag) //for NuPRO-E72 unsigned long tempCount; unsigned int registerValue; outportb(IT8783_ioPort, 0x07); outportb(IT8783_ioPort+1, 0x07);// Device 7 outportb(IT8783_ioPort, 0xf8); outportb(IT8783_ioPort+1, 0x00);// PLED mapping to...
  • Page 85 NuPRO-E72 outportb(IT8783_ioPort+1, registerValue); outportb(IT8783_ioPort, 0xf8); outportb(IT8783_ioPort+1, 0x1f);// PLED mapping to GP37 outportb(IT8783_ioPort, 0xf9); registerValue = inportb(IT8783_ioPort + 1); registerValue |= 0x02; registerValue &= 0xfb; outportb(IT8783_ioPort+1, registerValue); outportb(IT8783_ioPort, 0x71); registerValue = inportb(IT8783_ioPort + 1); registerValue &= 0xfe; outportb(IT8783_ioPort+1, registerValue); outportb(IT8783_ioPort, 0x72);...
  • Page 86 registerValue = inportb(IT8783_ioPort+1); registerValue |= 0x80; tempCount = count_value; if(tempCount != 0) printf("WDT timeout in %d seconds.\n", tempCount); registerValue |= 0x40; //Enable WDT output through KBRST else printf("WDT is Disabled.\n"); registerValue &= 0xbf; //Disable WDT output through KBRST outportb(IT8783_ioPort+1, registerValue); // set WDT count is second outportb(IT8783_ioPort, 0x71);...

  • Page 87: C Appendix: System Resources

    NuPRO-E72 Appendix C - System Resources C.1 System Memory Map Address Range Address Size Description (decimal) Range (hex) FFE00000 – (4GB-2MB) 2 MB High BIOS Area FFFFFFFF (4GB-18MB) – FEE00000 – 1 MB FSB Interrupt Memory Space (4GB-17MB-1) FEEFFFFF (4GB-20MB) –...

  • Page 88: Io Map

    C.3 IO Map Hex Range Device 000-01F DMA controller 1, 8237A-5 equivalent 020-02D and 030-03F Interrupt controller 1, 8259 equivalent 02E-02F,04E-04F LPC SIO (ITE8783) configuration index/data registers 040-042, 050-052 Timer, 8254-2 equivalent 060, 062, 064, 066 8742 equivalent (keyboard) NMI control and status 070-077 Real Time Clock Controller (bit 7 -NMI mask) 080-091...

  • Page 89: Interrupt Request (Irq) Lines

    NuPRO-E72 Note: A read to this address will subtractively go to PCI, where it will master abort. C.4 Interrupt Request (IRQ) Lines IRQ Lines PIC Mode Typical Interrupt IRQ# Connected to Pin Available Resource Counter 0 Keyboard controller Cascade interrupt from...
  • Page 90 IRQ Lines APIC Mode Typical Interrupt IRQ# Connected to Pin Available Resource System Timer Keyboard controller PCI / ISA Serial Port 2 (COM2) / IRQ3 via SERIRQ, Note (1) PCI / ISA IRQ3 at ISA bus Serial Port 1 (COM1) / IRQ4 via SERIRQ, Note (1) PCI / ISA...

  • Page 91: Table C-5: Irq Lines Apic Mode

    NuPRO-E72 Typical Interrupt IRQ# Connected to Pin Available Resource PCIE Port 0/1/2/3/4/5/6/7, P.E.G. Root Port, SATA Host controller, SMBus Controller, Thermal Controller, SOL (COM7) PCIE Port 0/1/2/3/4/5/6/7, P.E.G. Root Port, SATA Host controller, SATA Host controller#1, PCH internal GBE controller,...
  • Page 92 PCI Configuration Space Map Bus # Device # Function # Routing Description Intel Host Bridge Internal Intel IGD 0FFH P.E.G. Port Intel Integrated Graphics Internal Device Intel Management Engine Internal Interface #1 Intel Management Engine Internal Interface #2 Internal IDE-R controller Internal PCI Serial controller Internal...

  • Page 93: Table C-6: Pci Configuration Space Map

    NuPRO-E72 Bus # Device # Function # Routing Description 0FFh Internal PCIE Port #3 0FFh Internal Intel 82574L LAN Controller 0FFh Internal PCIE Port #5 0FFh Internal USB 3.0 Controller 0FFh Internal PCIE Port #7 Internal PCI Slot 0 Internal...

  • Page 94: Table C-7: Pci Interrupt Routing Map

    PCI Interrupt Routing Map PIRQ INT Line INTA INTB INTC INTD P.E.G. Root Port INTA INTB INTC INTD SATA Controller SATA Controller 1 SMBus controller Thermal Controller EHCI 1 EHCI 2 Intel GBE HECI host 1 HECI host 2 IDER Controller KT Controller PCIE port 0 INTA INTB INTC INTD...

  • Page 95: Important Safety Instructions

    NuPRO-E72 Important Safety Instructions For user safety, please read and follow all instructions, WARNINGS, CAUTIONS, and NOTES marked in this manual and on the associated equipment before handling/operating the equipment. Read these safety instructions carefully. Keep this user’s manual for future reference.
  • Page 96 Never attempt to fix the equipment. Equipment should only be serviced by qualified personnel. A Lithium-type battery may be provided for uninterrupted, backup or emergency power. Risk of explosion if battery is replaced with one of an incorrect type. Dispose of used batteries appropriately. WARNING: Equipment must be serviced by authorized technicians when:...

  • Page 97: Getting Service

    San Jose, CA 95138, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-360-0222 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd. Address: (201203) 300 Fang Chun Rd., Zhangjiang Hi-Tech Park Pudong New Area, Shanghai, 201203 China Tel: +86-21-5132-8988 Fax: +86-21-5132-3588 Email: market@adlinktech.com...
  • Page 98 84 Genting Lane #07-02A, Cityneon Design Centre Singapore 349584 Tel: +65-6844-2261 Fax: +65-6844-2263 Email: singapore@adlinktech.com ADLINK Technology Singapore Pte. Ltd. (Indian Liaison Office) Address: #50-56, First Floor, Spearhead Towers Margosa Main Road (between 16th/17th Cross) Malleswaram, Bangalore - 560 055, India Tel: +91-80-65605817, +91-80-42246107 Fax:...
