- Page 1 NuPRO-825 PICMG 1.0 Half-Size Pentium M SBC User’s Manual Manual Rev. 1.00 Revision Date: July 27, 2005 Part No: 50-13049-100 Advance Technologies; Automate the World. This datasheet has been downloaded from http://www.digchip.com at this page...
- Page 2 Copyright 2005 ADLINK TECHNOLOGY INC. All Rights Reserved. The information in this document is subject to change without prior notice in order to improve reliability, design, and function and does not represent a commitment on the part of the manufacturer.
- Page 3 Getting Service from ADLINK Customer Satisfaction is top priority for ADLINK Technology Inc. Please contact us should you require any service or assistance. ADLINK TECHNOLOGY INC. Web Site: http://www.adlinktech.com Sales & Service: Service@adlinktech.com TEL: +886-2-82265877 FAX: +886-2-82265717 Address: 9F, No. 166, Jian Yi Road, Chungho City,...
-
Page 5: Table Of Contents
Table of Contents List of Tables................iii List of Figures ................. v 1 Introduction ................ 1 NuPRO-825 Block Diagram..........2 EM-64 CPU Module Features..........3 ProCB-825 Features............4 ICH5 I/O Controller Hub ..........6 Ethernet Controller ............9 Winbond W83627HF Super I/O ........10 NuPRO-825 Mechanical Drawing........ - Page 6 Installing the First Memory Module ....... 31 Installing the second memory module ......32 Heat Sink Installation ............34 Connecting IDE Devices to the NuPRO-825 ..... 35 BIOS Configuration Overview ..........35 Operating System Installation ..........36 4 Device Driver Installation ..........35 Intel®...
-
Page 7: List Of Tables
Table 1-2: ProCB-825 PCI Resource Allocation ......8 Table 1-3: ProCB-825 GPIO table on ICH5 ....... 9 Table 1-4: ProCB-825 Carrier Board Layout ......13 Table 1-5: NuPRO-825 Specifications ........14 Table 3-1: NuPRO-825 Memory Compatibility ......31 List of Tables... - Page 8 List of Tables...
-
Page 9: List Of Figures
List of Figures Figure 1-1: NuPRO-825 Block Diagram........2 Figure 1-2: EM-64 Functional Diagram........4 Figure 1-3: NuPRO-825 Mechanical Drawing......11 Figure 1-4: ProCB-825 Carrier Board Layout ......12 Figure 3-1: Heat Sink Installation..........30 Figure 3-2: CPU Installation............30 Figure 3-3: First Memory Module Installation...... -
Page 11: Introduction
Introduction The NuPRO-825 single board computer is comprised of the ProCB-825, a PICMG 1.0 compliant half-size single carrier board, and the EM-64 CPU module. It features a single Intel® Pentium® M processor with 1MB L2 cache in a 478-pin Micro-FCPGA package, and is validated with the Intel®... -
Page 12: Nupro-825 Block Diagram
1.1 NuPRO-825 Block Diagram EM-64 CPU Module ProCB-825 Carrier Board Figure 1-1: NuPRO-825 Block Diagram Introduction... -
Page 13: Cpu Module Features
1.2 EM-64 CPU Module Features The ADLINK EM-64 CPU uses an Intel® Pentium® M processor and is specifically designed for embedded, fanless applications. The EM-64 and ProCB-825 are connected by a proprietary high-speed interface which provides: 1. High-speed bus between northbridge 855GME and south bridge ICH5 2. -
Page 14: Procb-825 Features
Figure 1-2: EM-64 Functional Diagram 1.3 ProCB-825 Features The ProCB-825 is the carrier board for the NuPRO-825 and supports various I/O functions and display interfaces. The following table lists the features of ProCB-825. Introduction... -
Page 15: Table 1-1: Procb-825 Feature Summary
Supports Ultra 100 DMA mode transfer One 40 Pin connector (Primary) and one CF slot (Secondary) Two Gigabit Ethernets with 82540EM that co-layout with 10/100 Ethernet controller 82562EZ. Wake on LAN support on LAN1 WFM 2.0 compliance Data transfer rate up to 150MB/s S-ATA Two port S-ATA channel support 5V, 32-bit interface at up to 33MHz with PCI golden fingers... -
Page 16: Ich5 I/O Controller Hub
ICH5 I/O Controller Hub The ProCB-825 is equipped with the highly integrated, multi-functional ICH5 I/O Controller Hub that provides the following functions and capabilities: PCI Local Bus Specification, Revision 2.3 with support for 33 MHz PCI operations. PCI slots (supports up to six Req/Gnt pairs) ACPI power management logic support Enhanced DMA controller, interrupt controller, and timer functions... - Page 17 IDE Interface The fast IDE interface supports up to four IDE devices providing an interface for IDE hard disks and ATAPI devices. Each IDE device can have independent timings. The IDE interface supports PIO IDE transfers up to 16MB/s and Ultra ATA transfers up 100MB/s.
-
Page 18: Table 1-2: Procb-825 Pci Resource Allocation
LPC/Firmware Hub System BIOS flash, SST 49LF004A, in 4Mb capacity, is compatible with Intel® 82802 Firmware Hub (FWH) device. BIOS write-protect function can be enabled/disabled in the BIOS option menu. System Management Bus The ICH5 provides a System Management Bus (SMBus) Specification, Version 2.0 compliant Host Controller as well as an SMBus Slave Interface. -
Page 19: Ethernet Controller
GPIO Table The ProCB-825 provides one GPIO controller. ICH5 Description GPI[6] P66DECT Primary IDE mode detect GPI[7] S66DECT Secondary IDE mode detect GPO[19] LAN1_DISJ LAN1 disable GPO[20] LAN2_DISJ LAN2 disable GPO[21] FWH_WPJ BIOS write protect GPO[22] TBLOCKJ Top Block Lock GPIO[13] LPC PME PME of LPC... -
Page 20: Winbond W83627Hf Super I/O
Winbond W83627HF Super I/O The ProCB-825 is equipped with a Winbond W83627HF Super I/O that has the following functions and capabilities: UART The serial port supports all functions of a standard 16550 UART including hardware flow and control interface. The UART performs serial-to-parallel conversion on data charac- ters received from a peripheral device or a modem and paral- lel-to-serial conversion on data characters received from the... -
Page 21: Nupro-825 Mechanical Drawing
1.4 NuPRO-825 Mechanical Drawing ProCB-825 Carrier Board EM-64 CPU Module Figure 1-3: NuPRO-825 Mechanical Drawing Introduction... -
Page 22: Procb-825 Components And Connectors
1.5 ProCB-825 Components and Connectors Figure 1-4: ProCB-825 Carrier Board Layout (see Table 1-4 below) Introduction... -
Page 23: Table 1-4: Procb-825 Carrier Board Layout
Carrier Board Layout Legend DVI Pin Header (CN1) ATX I/F connector (CN2) LVDS Connector (CN3) RS-232 Connector (CN4) IRDA Pin Header (CN6) IDE Connector (CN7) CF SKT (CN8) Floppy Connector (CN9) Print Port Connector (CN10) KB,MS Combo Pin Header (CN11) VGA Connector (CN12) External Temperature Sensor (CN13) External USB Connector (CN14) -
Page 24: Specifications
191mm x 122mm Operating Temp. -5 to 55ºC Humidity 5% to 95% non-condensed Windows 2000, Windows XP, Linux Fedora Core 3 Operating System (other OS support upon request) Safety Certificates CE, FCC Class A and Tests Table 1-5: NuPRO-825 Specifications Introduction... -
Page 25: Unpacking Checklist
Check the following items are included in the package, if there are any items missing, please contact your dealer: Included Items ADLINK All-in-One CD-ROM NuPRO-825 carrier board with EM-64 CPU module COM/LPT port bracket 2-port USB bracket ATA-100 and FDD cable... - Page 26 Introduction...
-
Page 27: Connectors And Jumpers
Connectors and Jumpers This chapter will familiarize the user with the connectors and jumpers on the NuPRO-825. Please refer to Figure 1-4: ProCB- 825 Carrier Board Layout for connector and jumper locations. 2.1 Connector Pin Assignments VGA Connector (CN12) Signal... -
Page 28: Ethernet Connectors
Ethernet Connectors NuPRO-825DV Dual Gigabit Ethernet (LAN1: CN16, LAN2: CN17) LAN1 Signal LAN2 Signal Function LAN1_TDP1 LAN2_TDP1 Transmit Data1 + LAN1_TDN1 LAN2_TDN1 Transmit Data1 - LAN1_RDP2 LAN2_RDP2 Receive Data2 + LAN1_RDP3 LAN2_RDP3 Receive Data3 + LAN1_RDN3 LAN2_RDN3 Receive Data3 - LAN1_RDN2 LAN2_RDN2 Receive Data2 -... -
Page 29: Com Ports (Cn4)
COM Ports (CN4) Signal Function Data Carrier Detect Receive Data Transmit Data Data Terminal Ready Ground Data Set Ready Request to Send Clear to Send Ring Indicate No Connect Primary IDE Connector (CN7) Signal Name Signal Name Reset IDE Ground Host data 7 Host data 8 Host data 6... -
Page 30: Front Panel Pin Header (Cn2)
Front Panel Pin Header (CN2) Signal Function Pin Group Power Power LED PLED Power LED Signal KEYLOCK Keyboard lock Key Lock Ground Ground No connect ATX Power PWRON Power-on signal Connector +5VSB Standby Power Key Pin WDSPK Speaker signal No connect Chassis Speaker No connect... -
Page 31: Floppy Connector (Cn9)
Floppy Connector (CN9) Signal Name Pin Pin Signal Name Ground Drive density selection Ground No Connect No Connect Drive density selection Ground Index Ground Motor enable 0 Ground Drive select 1 Ground Drive select 0 Ground Motor enable 1 Ground Direction Ground Step... -
Page 32: Usb Pin Header (Cn14)
USB Pin Header (CN14) Pin Signal Name Pin Signal Name USBP2N USBP3N USBP2P USBP3P FAN Connectors (FN1) Signal Name Fan Power Fan Speed IrDA Connector (CN6) Signal Name No connect IrRXD Ground IrTXD External Temperature Sensor Connector (CN13) Signal Function TSEN_G Thermal resistor Ground TSEN_I... -
Page 33: External Ps/2 Kb/Ms Connector (Cn11)
External PS/2 KB/MS Connector (CN11) (proprietary cable provided for OEM only) Signal Name Keyboard data Keyboard clock Mouse data Mouse clock S-ATA 1, 2 Connector (CN19/CN20) Signal Name S-ATA_TXP S-ATA_TXN S-ATA_RXN S-ATA_RXP USB Connector (CN18/CN21) Signal Function Power USB - Data (-) USB + Data (+) -
Page 34: Board-To-Board Interface Pin Definition (Cn15)
Board-to-Board Interface Pin Definition (CN15) Segment 1 (Metal Plane: GND) Signal Pin Pin Signal DVOD0 HI_HL10 DVOD1 HI_HL9 DVOD2 VCCP HI_HL8 DVOD3 HI_HL7 DVOD4 Segment 1 DVOD5 HI_HL6 HI_HL5 DVOD6 DVOD7 HI_HL4 DVOD8 HI_HL3 +3.3V DVOD9 HI_HL2 DVOD10 HI_HL1 DVOD11 HI_HL0 DVOCLK HI_STB... - Page 35 IYAP1 IYAM1 CLK33 IYAP0 CLK14 IYAM0 ADDCDATA CLK33_2 Segment 3 (Metal Plane: GND) Signal Pin Pin Signal ADDCCLK PCIRSTJ HIGNNE# HSMI# HNMI HFERR# PWROK_MCH CPUSLP# CPUPWGD DPRSLPVR SMD_SYS DPSLP# SMC_SYS TMDS_I2CC TMDS_I2CD MI2CDATA 101 102 MI2CCLK THERTRIP# 103 104 VRPWRGD 105 106 HINIT# HA20M#...
-
Page 36: Golden Fingers - Top Side
Golden Fingers - Top Side Signal Function REQ# No Connection Ground GNT# No Connection No Connection PME# PCI Slot Wake Up +12V 12V Power AC_SDIN0 No Connection Ground AC_SDIN1 No Connection 5V Power 5V Power Ground AC_BITCLK No Connection +3.3V No Connection +3.3V No Connection... -
Page 37: Golden Fingers - Bottom Side
Golden Fingers - Bottom Side Signal Function NO Connection NO Connection NO Connection SM_DAT SM Bus Data SM_CLK SM Bus Clock Ground 5VSB 5V Standby Power KB_CLK Keyboard Clock Ground KB_DAT Keyboard Data 5V Power Ground PSON Power On PWRGD Power Good +3.3V No Connection... -
Page 38: Jumper Settings
2.2 Jumper Settings Clear CMOS Jumper (JP2) The ProCB-825 has a clear CMOS jumper to allow the user to clear CMOS values to default values if necessary. To clear the CMOS values, apply a mini jumper to short the pins 2 and 3. Jumper Status Normal (default) -
Page 39: Getting Started
NuPRO-825. Hardware installation, BIOS setup and operating system installation are described. Note that the NuPRO-825 is shipped with CPU and RAM pre-installed. Installation of the CPU and RAM are performed at the ADLINK factory and the procedures outlined in the following sections are for user reference. -
Page 40: Figure 3-1: Heat Sink Installation
Figure 3-1: Heat Sink Installation Figure 3-2: CPU Installation Getting Started... -
Page 41: Memory Installation
At least one memory module will be installed in DIMM Slot 1 when the NuPRO-825 is shipped. You can upgrade the amount of RAM by changing the existing memory module, or by adding a second SDRAM module. It is necessary to disassemble the NuPRO-825... -
Page 42: Installing The Second Memory Module
into the slot until the security latches on the sockets have locked into place on each side of the module (refer to Figure 3.3: First Memory Module Installation). There is an alignment key on the memory module to assist users with installation. Note: Ensure that the CPU socket is in the locked position, otherwise the memory module will not seat properly. -
Page 43: Figure 3-4: Em-64 Cpu Module Removal
Figure 3-4: EM-64 CPU Module Removal Figure 3-5: Second Memory Module Installation Getting Started... -
Page 44: Heat Sink Installation
3.3 Heat Sink Installation After you have finished installing the CPU and/or memory mod- ules, replace the heat sink by replacing the four mounting screws. Be sure that the raised blocks on the underside of the heat sink are aligned with the CPU and northbridge on the EM-64 CPU Module (refer to Figure 3-6: Heat Sink Installation below). -
Page 45: Connecting Ide Devices To The Nupro-825
Plug the board end of the cable into one of the IDE connectors on the NuPRO-825. Make sure pin 1 of the ribbon cable connector is aligned with pin 1 of the IDE device connector. -
Page 46: Operating System Installation
3.6 Operating System Installation For further information about your operating system, refer to the documentation provided by the operating system vendor. Installing peripheral devices: NuPRO devices are automatically configured by the BIOS during the boot sequence. Most operating systems require initial installation on a hard drive from a floppy or CDROM drive. -
Page 47: Device Driver Installation
Device Driver Installation To install drivers for the NuPRO-825, refer to the procedures described in this chapter. The drivers are located in the following directories of the ADLINK All-in-One CD: Chipset driver X:\NuPRO\NuPRO-825\chipset\ VGA driver X:\NuPRO\NuPRO-825\VGA\ LAN driver X:\NuPRO\NuPRO-825\LAN\ 4.1 Intel® 855GME/ICH5 Chipset This section describes the installation procedure for the Intel®... -
Page 48: Vga Driver Installation
Intel® software utilities package include a Diagnostics Utility, Makedisk Utility, and the 10/100/1000Mbps Ethernet device drivers. All drivers and utilities are stored in the ADLINK All-in-One CD under the directory: X:\NuPRO\NuPRO-825\LAN, where X is the CD drive letter. Device Driver Installation... - Page 49 ADLINK All-in-One CD. After installing the OS, update the driver by following these steps: 1. Run the self-extracting file pro2kxpm.exe in the following directory:X:\NuPRO\NuPRO-825\LAN. 2. Click through the subsequent pages to extract the files to the default location c:\Intel9.1 3.
-
Page 51: Warranty Policy
Warranty Policy Thank you for choosing ADLINK. To understand your rights and enjoy all the after-sales services we offer, please read the following carefully. 1. Before using ADLINK’s products please read the user manual and follow the instructions exactly. When sending in damaged products for repair, please attach an RMA application form which can be downloaded from: http:// rma.adlinktech.com/policy/. - Page 52 3. Our repair service is not covered by ADLINK's two-year guarantee in the following situations: Damage caused by not following instructions in the user's manual. Damage caused by carelessness on the user's part during product transportation. Damage caused by fire, earthquakes, floods, lightening, pollution, other acts of God, and/or incorrect usage of voltage transformers.
