IMPORTANT! Read and save these instructions. This manual to be left with the equipment.
INSTALLATION MANUAL
Ultrasonic Humidifier
US-Series
Humidification and Evaporative Cooling

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the US Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Condair US Series

Summary of Contents for Condair US Series

  • Page 1 IMPORTANT! Read and save these instructions. This manual to be left with the equipment. INSTALLATION MANUAL Ultrasonic Humidifier US-Series Humidification and Evaporative Cooling...
  • Page 2 WARNING May present health risk if not maintained as instructed. Peut présenter un risque pour la santé si l'entretien n'est pas effectué conformement au mode d'emploi. Riesgo para la salud si no se siguen las instrucciones de mantenimiento.
  • Page 3 IMPORTANT! Read and save these instructions. This manual to be left with the equipment. INSTALLATION MANUAL Ultrasonic Humidifier US-Series Humidification and Evaporative Cooling...
  • Page 4 Liability Notice Condair Group AG does not accept any liability due to incorrect installation, maintenance or operation of the equipment, or due to the use of parts/components/equipment that are not authorized by Condair Group AG Copyright Notice Copyright 2020, Condair Group AG, All rights reserved.

  • Page 5: Table Of Contents

    Storage, Packaging, and Transportation Safety Precautions Compliance For Your Safety Hygiene Hygiene Risk Management 3.1.1 Guidelines to Keep a Clean System and Prevent Micro-organism Growth 3.1.2 Condair Service Offering Product Description General Description Model Designation Functional Description Options Accessories Product Specifications Technical Data 5.1.1...
  • Page 6 7.4.4 Drainage Requirements 7.4.5 Power Supply Requirements Humidity Control Systems 7.5.1 Control Device Locations 7.5.2 Permissible Control Signal Inputs Best Practices 7.6.1 Remote Ultrasonic Blower Pack Installation Installation 7.7.1 Safety 7.7.2 Cleaning 7.7.3 Diluting your Disinfecting Solution (H2O2) to 0.1% 7.7.4 Mounting the Humidifier 7.7.4.1 Mounting Checklist...

  • Page 7: Introduction

    If you have additional questions, please contact your Condair representative. They will be glad to assist you. General 1.2.1 Limitations of the Manual The subject of this manual is the Ultrasonic Humidifier in its different versions.

  • Page 8: Available Manuals And Languages

    Check the goods against the packing slip to ensure that all items have been delivered. Report any shortages to your Condair representative within 48 hours of receipt of the goods. Condair does not assume responsibilities for any shortages beyond this period.

  • Page 9: Safety Precautions

    Follow all local guidelines and regulations regarding the installation and operation of the unit; this includes (and not limited to) mounting, plumbing, water, gas, ventilation, and electrical connections. Please consult your local Condair representative to learn more. Introduction | 9...

  • Page 10: For Your Safety

    Requirements" on page 27 for details. Any other type of application, without the express written consent of Condair, is considered to be NOT conforming to its intended purpose, and may lead to dangerous operation and will void the warranty. In order to operate the equipment in the intended manner all information contained in this manual, in particular the safety instructions, must be observed closely.
  • Page 11 Safety Precautions that Must be Observed DANGER! Risk of electric shock! The unit is mains powered. Using the On/Off switch on the humidifier to shut down the unit will NOT shut off power to the control cabinet. Live parts may be exposed when the access panels or doors are removed.
  • Page 12 Modifications to the Unit Prohibited Modifications are NOT permitted on the Ultrasonic Humidifier without the express written consent of Condair. Safety Labels The safety label (hygiene) is found on the right wall inside the plumbing cabinet (on the panel separating the electrical cabinet).

  • Page 13: Hygiene

    There are multiple points in the humidification system where a contamination can occur. It is the responsibility of the customer and of Condair to ensure that health hazards due to contamination are reduced to acceptable levels. The use of a hygiene risk assessor is recommended.

  • Page 14: Guidelines To Keep A Clean System And Prevent Micro-Organism Growth

    Training and guidance. Note: * Condair uses a quick method for measuring bacterial activity in the water with the use of BactiQuant (BQ). Once the water sample has been taken, the bacteriological quality of the water is read within 30 minutes, and the Condair service team will disinfect the system if necessary.

  • Page 15: Product Description

    Product Description General Description The Ultrasonic Humidifier is a steam-less humidifier. To humidify the space, the Ultrasonic Humidifier creates mist using piezoelectric transducers. Mist is expelled from the unit with internal fans, and an Ultrasonic Blower Pack (if installed), into the space. Mist is then absorbed into the air. The Ultrasonic Blower Pack comes in 4 different output capacities;...

  • Page 16: Options

    Treated water enters the humidifier's reservoir from an inlet located at the bottom of the unit. The water that enters the humidifier's reservoir must be treated to remove minerals, bacteria and fungi, and should otherwise be pure to prolong the service cycle of the unit and, above all, safeguard the public. An accumulation of minerals will result in scale, and an accumulation of bacteria and fungi will result in unhygienic conditions in the space.
  • Page 17 Table 2: Ultrasonic Humidifier Accessories Accessory Application Disinfection kit Disinfecting and cleaning kit. (PN: 2594996) Air filter kit, humidifier Replacement air intake filter(s) for the humidifier. (PN: 2594401 US 7-20) (PN: 2594995 US 40) Air filter kit, blower pack Replacement air filters for the Ultrasonic Blower Pack. (PN: 2588764) Manuals (PN: 2588786 Installation Manual)

  • Page 18: Product Specifications

    Product Specifications Technical Data 5.1.1 Capacity Table 3: Ultrasonic Humidifier Capacity Capacity Model Housing Size at 120V/208/240V/1 Mist Production Power Rating US 7 Medium 3 kg/h (6.6 lb/h) 250 W US 13 6 kg/h (13.2 lb/h) 250 W US 20 9 kg/h (19.8 lb/h) 650 W US 40*...

  • Page 19: Dimensions

    5.1.3 Dimensions Table 7: Ultrasonic Humidifier Dimensions (excludes flexible tubes) Model Housing Dimensions height x width x depth US 7 Medium 780 x 530 x 406 mm US 13 (30.71 x 20.87 x 15.96 in) US 20 US 40 Large 780 x 1000 x 406 mm (30.71 x 39.37 x 15.96 in) Table 8:...
  • Page 20 Table 9: Ultrasonic Humidifier, Maximum External Fusing — Single-Phase 110-120V/1~ 208V/1~ 220-240V/1~ Maxim Maxim Maximu Maxim Maxim Maximu Maxim Maxim Maximu Output Curren External Output Curren External Output Curren External Disconn Disconn Disconn US 7 744 W 6.2 A 15 A 744 W 3.6 A 15 A...

  • Page 21: Specification Drawings

    Specification Drawings Figure 2 - Specification Drawing Medium Housing ( US 07-20) A. 405.4 mm (15.96 in) E. 54 mm (2.13 in) I. 204.6 mm (8.05 in) B. 780 mm (30.71 in) F. 89.7 mm (3.53 in) J. 96.5 mm (3.8 in) C.
  • Page 22 Figure 3 - Specification Drawing Large Housing ( US 40) A. 75 mm (2.95 in) I. 590 mm (23.23 in) Q. 97 mm (3.82 in) B. 91.5 mm (3.60 in) J. 263.5 mm (10.37 in) R. 205 mm (8.07 in) C.

  • Page 23: Installation And Planning

    Observe and comply with all local and national codes dealing with water and electrical installations. Condair does not accept any liability for installation of humidification or dehumidification equipment by unqualified personnel, or the use of equipment and parts that are not authorized by Condair.

  • Page 24: Installation Overview

    (P/N: 2588705_B_EN_2005_UB_IOM). The Ultrasonic Humidifier runs optimally with treated water, such as RO water (recommended) and DI water (see Condair representative). A typical installation will have an RO-U System with buffer tank. Refer to the Reverse Osmosis System Installation, Operation, and Maintenance Manual (P/N: 2594385_B_EN_2005_RO_...

  • Page 25: Location Requirements

    Figure 4 - Typical Installations* Installation with the Ultrasonic Blower Pack Flexible tubes Electrical disconnect, high voltage supply (supplied by others) Drain line to air gap funnel Trap Expansion (buffer) tank R.O. system Note: * Water, electrical, and drain connections not shown for the large model. Additionally, two Ultrasonic Blower Packs may also be installed in the same room, or on the same vertical surface.

  • Page 26: Clearance Requirements

    Figure 5 below The clearances shown in are for reference only, and are suggested for ease of maintenance. Consult local installation codes. Condair does not accept responsibility for violations of installation codes. Figure 5 - Suggested Clearances Ultrasonic Humidifier Direct-mount installation...

  • Page 27: Site Requirements

    Site Requirements Prepare the Ultrasonic Humidifier for installation by ensuring the following site requirements are satisfied. Report any discrepancies to your Condair representative. Ensure that the installation of the Ultrasonic Humidifier is compliant with all applicable local regulations and codes.

  • Page 28: Water Supply Requirements

    The R.O system (recommended) must be installed as close as possible to the humidifier. Should a DI system be installed, contact your Condair representative. Upon completion of installation, flush the water supply and drain lines to clear out debris in the lines.
  • Page 29 D.I. (optional - not supplied) R.O. Figure 7 - Water Supply Requirements Water from the source entering the RO-U system Water entering the US Installation and Planning | 29 2588786_B_EN_2005_US_IM...
  • Page 30 * If the water entering the RO-U system is greater than the values indicated in this table, install a water softener between the water supply and the Reverse Osmosis System. ** Contact your Condair representative if the conductivity of the supply water is greater than 350 µS/cm. 30 | Installation and Planning...

  • Page 31: Drainage Requirements

    < 200 CFU/ml for industrial applications** follow applicable regulations * if the conductivity of the water entering the RO-U system is greater than 350 µS/cm, contact your Condair representative . ** CFU leaving the unit via mist should be <1000 CFU/ml for industrial applications. Keep the CFU entering the humidifier as low as possible, such that the CFU leaving the unit is within acceptable guidelines.

  • Page 32: Humidity Control Systems

    Humidity Control Systems 7.5.1 Control Device Locations Figure 8 The following schematic describes a potential system set-up with respect to control devices. Refer to below Φ Figure 8 - Control Device System Set-up Schematic Space to humidify On/Off Humidistat or Modulating Humidistat and Sensor Note 7-1 Humidity sensors and humidistats can be modulating or On/Off.

  • Page 33: Best Practices

    7.6.1 Remote Ultrasonic Blower Pack Installation Use Condair flexible tubes that are provided by your Condair representative. Mist connection materials from another manufacturer may adversely affect the operation of the unit. The length of the mist line should be kept as short as possible. It should not exceed the maximum equivalent length of 2 m (6.56 ft).
  • Page 34 This should be performed manually or through changing the demand signal (full demand to mist; zero stop mist and allow to drain). Condair provides a cleaning and disinfecting kit for the Ultrasonic Humidifier (P/N: 2594996) IMPORTANT! Avoid cleaning with hard or rough materials, such as steel wool, or metal brushes. Abrasions on the surface of any components may prevent micro-organisms from being cleaned easily.

  • Page 35: Diluting Your Disinfecting Solution (H2O2) To 0.1

    7.7.3 Diluting your Disinfecting Solution (H ) to 0.1% A 0.1% hydrogen peroxide solution is recommended to disinfect the unit. If a 0.1% solution is not readily available, you may need to dilute your current solution. General Formula Before mixing your solutions, you should know the following: The desired concentration of disinfectant (Hydrogen Peroxide) in the mixture (0.1%).

  • Page 36: Mounting The Humidifier

    Table 12: Volume of water and H required for 0.1% hydrogen peroxide solution. Desired concentration of Hydrogen Peroxide: 0.1% Desired volume of Volume Units to Mix diluted solution to Produce 0.1% Hydrogen Peroxide (0.1% hydrogen peroxide) Water Halomist, H (5%) Water (3%) 1 unit...
  • Page 37 Figure 9 - Lag Bolt Hole Locations for Medium and Large Condair US Rear view of medium Ultrasonic Humidifier Rear view of large Ultrasonic Humidifier Clearance from the mounting surface at point A, 5 mm (0.25 in) Screw (not supplied) Table 13:...

  • Page 38: 7.7.4.1 Mounting Checklist

    Locate 2x4 wooden studs or equivalent support on the mounting surface. Use a level and mark points A and B for the lag bolts. Refer to Figure 9 on the previous page Install the lag bolts (supplied by others) at the marked points A. Allow the heads of the screws to extend 5 mm (0.25 in) from the mounting surface so that the humidifier can be installed on bolts.

  • Page 39: 7.7.5.1 Water Supply Connections Checklist

    Figure 10 - Water Supply Connections Water supply inlet Adapter* , 3/4 in BSPP to 1/2 in NPT (supplied) Water supply line * Hand-tighten the adapter to the inlet valve. 7.7.5.1 Water Supply Connections Checklist Water Supply Connection □ Has an R.O. or D.I. system been installed? □...
  • Page 40 Open the humidifier cabinet. Remove the clamp from the flexible tube. This will allow the flexible tube to pass through the top of the humidifier cabinet. Route the 'connecter' end (item 3) of the flexible tube to the top of the water reservoir. Secure the connection by gently inserting the connector and tube into the reservoir, as seen in Figure 11 below If the Ultrasonic Blower Pack is directly mounted on the humidifier, the mist channel connection extends...

  • Page 41: 7.7.6.1 Flexible Tube Connections Checklist

    7.7.6.1 Flexible Tube Connections Checklist □ Flexible tubes cleaned? □ The length of flexible tubes must be kept as short as possible □ Flexible tubes should allow condensate to flow back to the humidifier (otherwise, use condensate traps for drainage along the connection) 7.7.6.2 Connecting the Drain Line Refer to "Drainage Requirements"...

  • Page 42: Connecting The Ultrasonic Blower Pack

    Drain Line Connections Checklist Drain Line Connection □ Are all components and pipes secured and are all threaded connections securely tightened? □ Leak-free drain line? □ Air gap funnel has a minimum diameter of 64 mm (2-1/2 in)? □ Drain lines has a minimum internal diameter of 22 mm (7/8 in)? □...
  • Page 43 All electrical installation work must be performed only by a licensed electrician authorized by the customer. It is the customer’s responsibility to verify qualifications of the personnel. The electrical installation must be performed according to the wiring diagrams in this manual, the instructions in this section, as well as applicable national and local codes.

  • Page 44: 7.7.8.1 Installing External Electrical Connections

    7.7.8.1 Installing External Electrical Connections The different external connections to the Ultrasonic Humidifier are: "Power Supply Connection " below "External Safety Chain " on the facing page "Modulating Demand or Humidity Signal" on the facing page "Ohmic Humidity Controller (Passive)" on page 46 "VDC On/Off Humidistat"...
  • Page 45 External Safety Chain The potential-free contacts of external monitoring devices (ventilation interlock, safety high limit humidistat, airflow monitor, etc.) are connected to safety chain, K2, of the XE2 terminal block. Refer to Appendix: "Wiring Diagram Ultrasonic Humidifier - Medium" on page 56 Appendix: "Wiring Diagram Ultrasonic Humidifier - Large (A-unit)"...
  • Page 46 + – 1 2 3 4 5 6 7 8 9 Figure 15 - Modulating Demand or Humidity Signal Connection Control cabinet External Driver board Open the door panels to access the control cabinet of the Ultrasonic Humidifier. Ensure that the main power cable is properly grounded through the ground lug inside the control cabinet. Feed the external controller or humidity sensor cables through a cable gland or grommet located at the bottom of the unit, into the control cabinet.
  • Page 47 Ω Ω ...10k 1 2 3 4 5 6 7 8 9 Figure 16 - Ohmic Humidity Controller Connection Control cabinet External Driver board Open the door panels to access the control cabinet of the Ultrasonic Humidifier. Ensure that the main power cable is properly grounded through the ground lug inside the control cabinet.
  • Page 48 On/Off 1 2 3 4 5 6 7 8 9 Figure 17 - On/Off Humidistat Connection Control cabinet External Driver board Open the door panels to access the control cabinet of the Ultrasonic Humidifier. Ensure that the main power cable is properly grounded through the ground lug inside the control cabinet. Feed the external cables through a cable gland or grommet located at the bottom of the unit, into the control cabinet.

  • Page 49: 7.7.8.2 Electrical Connections Checklist

    7.7.8.2 Electrical Connections Checklist □ Power supply meet the voltage and current requirements shown on the specification label? Refer to "Model Designation" on page 15. □ Power supply have an external dedicated fused disconnect? □ Unit is using the correct external fusing? Refer to "Maximum External Fusing".

  • Page 50: Humidification Load Calculations

    For a straight, vertical flexible tube of length 2 m (6.6 ft), expect a 20% reduction in output capacity. The addition of angles in the flexible tube connection will decrease the output further. Please contact your Condair representative for more information on calculating mist losses. Humidification Load Calculations | 50...

  • Page 51: Commissioning

    First-time Commissioning The unit must always be commissioned for the first time by a service technician from your Condair representative, or by personnel who are well trained and authorized by the customer. For this reason, this manual only provides an outline, and not the details of the commissioning protocol.
  • Page 52 APPENDIX Appendix 2588786_B_EN_2005_US_IM...

  • Page 53: A Appendix: Installation Checklist

    A                 Appendix: Installation Checklist Mounting □ Unit installed in a suitable location? Refer to "Location Requirements" on page 25. □ Unit installed with suitable clearances? Refer to "Clearance Requirements" on page 26. □ Mounting surface is stable and capable of supporting the full operating weight of the unit? Refer to "Weights"...
  • Page 54 Electrical Connection □ Power supply meet the voltage and current requirements shown on the specification label? Refer to "Model Designation" on page 15. □ Power supply have an external dedicated fused disconnect? □ Unit is using the correct external fusing? Refer to "Maximum External Fusing".

  • Page 55: B Appendix: Wiring Diagram Ultrasonic Humidifier - Reservoir

    B                 Appendix: Wiring  Diagram Ultrasonic Humidifier - Reservoir MU-6 MU-5 MU-4 MU-3 MU-2 MU-1 LEVEL SWITCH MAIN TACH Figure 18 - Wiring Diagram of the Ultrasonic Humidifier Reservoir Legend CN1: Misting unit power input T1-T12: Transducers Internal fuse 48V (3.15mA, slow acting)

  • Page 56: C Appendix: Wiring Diagram Ultrasonic Humidifier - Medium

    C                 Appendix: Wiring  Diagram Ultrasonic Humidifier - Medium GNYE PSU1 PSU3 PSU2 SMPS SMPS ON/OFF SWITCH 24VDC/75VA 24VDC/100VA SMPS 48VDC/600VA -V +V +V -V To PSU1A -V (LARGE UNIT ONLY) 230VAC/50Hz To CN4 110...240V 50/60Hz (BLOWER CONTROL) UHUV-10...
  • Page 57 Legend Internal fuse 24 V supply (315 mA, slow acting) Jumper, do not remove Jumper, do not remove PSU1: Power supply 24 VDC 50 VA PSU2: Power supply 48 VDC 600 VA On/Off switch Rotary switch module identification: 0 Level, temperature and fan connection Missing units power connection XE1: Supply voltage terminal block...

  • Page 58: D Appendix: Wiring Diagram Ultrasonic Humidifier - Large (A-Unit)

    D                 Appendix: Wiring  Diagram Ultrasonic Humidifier - Large (A-unit) MODULE A GNYE - B(N) to X0 - B(L) to X0 to X0 - B(PE) GNYE GNYE PSU1 PSU3 PSU2 SMPS SMPS ON/OFF SWITCH 24VDC/75VA 24VDC/100VA SMPS...
  • Page 59 Figure 20 - Wiring Diagram of the Large Ultrasonic Humidifier Legend Internal fuse 24 V supply (315 mA, slow acting) Jumper, do not remove Jumper, removed on driver board A, installed on driver board B PSU1: Power supply 24 VDC 50 VA PSU2-PSU3: Power supply 48 VDC 600 VA On/Off switch...

  • Page 60: E Appendix: Wiring Diagram Ultrasonic Humidifier - Large (B-Unit)

    E                 Appendix: Wiring  Diagram Ultrasonic Humidifier - Large (B-unit) - A(N,L,PE) to X0 to X0 - A(N'L'PE') MODULE B to X0 - B(N) - B(L) to X0 - B(PE) GNYE to X0 PSU1 PSU3 PSU2...
  • Page 61 Legend Internal fuse 24 V supply (315 mA, slow acting) Jumper, do not remove Jumper, removed on driver board A, installed on driver board B PSU1: Power supply 24 VDC 50 VA PSU2-PSU3: Power supply 48 VDC 600 VA On/Off switch Rotary switch module identification: 0 Level, temperature and fan connection Missing units power connection...
  • Page 62 Notes:...
  • Page 63 Warranty Condair Inc. and/or Condair Ltd. (hereinafter collectively referred to as THE COMPANY), warrant for a period of two years after installation or 30 months from manufacturer’s ship date, whichever date is earlier, that THE COMPANY’s manufactured and assembled products, not otherwise expressly warranted, are free from defects in material and workmanship.
  • Page 64 CONSULTING, SALES, AND SERVICE: CANADA 2740 Fenton Road Ottawa, ON, K1T 3T7 U.S.A. 826 Proctor Avenue Ogdensburg, NY 13669 Tel: 1.866.667.8321 Fax: 613.822.7964 na.info@condair.com www.condair.com...
