7 Temperature tables
7.1 Tables
J2 (Supply), J3 (Suction), J4 (Liquid), J6 (Outdoor), J13 (Water and return)
Temperature Heater
(°C) (Ohms)
-40 328400
-39 310260
-38 292120
-37 273980
-36 255840
-35 237700
-34 224940
-33 212180
-32 199420
-31 186660
-30 173900
-29 164820
-28 155740
-27 146660
-26 137580
-25 128500
-24 121101
-23 114172
-22 107681
-21 101597
-20 95893
-19 90543
-18 85523
-17 80811
-16 76386
-15 72229
-14 68322
-13 64650
-12 61196
-11 57947
-10 54890
-9 52011
-8 49300
-7 46746
-6 44339
-5 42069
-4 39929
-3 37910
-2 36004
-1 34205
0 32506
1 30902
2 29385
3 27952
4 26596
5 25314
6 24101
30
Voltage
(V)
4,83795
4,82880
4,81855
4,80700
4,79388
4,77885
4,76689
4,75356
4,73862
4,72174
4,70254
4,68718
4,67015
4,65115
4,62983
4,60573
4,58365
4,56060
4,53657
4,51153
4,48547
4,45836
4,43019
4,40094
4,37061
4,33917
4,30662
4,27297
4,23818
4,20229
4,16528
4,12714
4,08789
4,04755
4,00613
3,96361
3,92007
3,87549
3,82989
3,78332
3,73581
3,68741
3,63811
3,58801
3,53708
3,48543
3,43309
Temperature Heater
(°C) (Ohms)
7 22952
8 21865
9 20836
10 19860
11 18936
12 18060
13 17229
14 16441
15 15694
16 14984
17 14311
18 13671
19 13064
20 12487
21 11938
22 11417
23 10921
24 10449
25 10001
26 9574
27 9167
28 8780
29 8412
30 8060
31 7726
32 7407
33 7103
34 6813
35 6536
36 6272
37 6020
38 5780
39 5550
40 5331
41 5122
42 4921
43 4730
44 4547
45 4373
46 4205
47 4046
48 3893
49 3746
50 3606
51 3472
52 3343
53 3220
54 3102
55 2989
56 2881
57 2777
58 2677
Voltage
(V)
3,38007
3,32649
3,27240
3,21776
3,16275
3,10736
3,05165
2,99570
2,93961
2,88331
2,82703
2,77066
2,71443
2,65828
2,60223
2,54650
2,49099
2,43578
2,38108
2,32672
2,27277
2,21941
2,16670
2,11438
2,06291
2,01201
1,96183
1,91237
1,86359
1,81566
1,76851
1,72229
1,67674
1,63217
1,58851
1,54544
1,50350
1,46234
1,42230
1,38277
1,34454
1,30699
1,27017
1,23442
1,19956
1,16538
1,13221
1,09984
1,06834
1,03775
1,00784
0,97865
