TMI Gebrauchsanleitung
TMI Manual
1
Allgemeine Beschreibung
2
Sicherheitshinweise
2.1 Bestimmungsgemäße Verwendung
2.2 Installation & Inbetriebnahme
2.3 Anschlüsse prüfen
2.4 Einschalten des Systems
2.5 Messwerte prüfen
2.6 Funktionsfähigkeit prüfen
2.7 Funktionsstörung
3
Elektrische Daten
4
Montagehinweis
5
Anschlüsse
6
Einbau und Installation
6.1 Flansch
6.1.2 Gewinde M18x1,5
6.1.3 Gewinde 3/4"-16UNF
6.2 Positionsgeber
7
Elektrischer Anschluss
7.1 Code 101/103
7.2 Code 102
7.3 Code 201/203/205
7.4 Steckerbelegung
8
Ausgangssignale
8.1 Impuls-Schnittstelle
8.2 SSI-Schnittstelle
8.3 DyMoS-Schnittstelle
8.4 Analoge Schnittstellen
8.5 Analog Option 2 Positionsgeber
9
Spezifische Stecker auf Anfrage
9.1 Code 103
9.2 Code 111
10
Teach-In Funktion
11
Notwendiges Zubehör
12
Optionales Zubehör
13
Bestellcode
Artikelnummer / Item number: 516684/04
2
2
2
2
2
2
2
2
2
3
3
3
4
4
5
6
7
8
8
8
8
9
10
10
10
10
11
11
12
12
12
13
14
14
14
Änderungen vorbehalten / Subject to change without notice
1
General description
2
Safety instructions
2.1 Intended conditions of use
2.2 Installation & startup
2.3 Check connections
2.4 Turning on the system
2.5 Check measured values
2.6 Check functionality
2.7 Failure malfunction
3
Electrical data
4
Instruction for installation
5
Wiring
6
Mounting and installation
6.1 Flange
6.1.2 Thread M18x1,5
6.1.3 Thread 3/4"-16UNF
6.2 Position marker
7
Electrical connection
7.1 Code 101/103
7.2 Code 102
7.3 Code 201/203/205
7.4 Pin configuration
8
Output signals
8.1 Pulse interface
8.2 SSI interface
8.3 DyMoS interface
8.4 Analog output
8.5 Analog dual output option
9
Special connectors on request
9.1 Code 103
9.2 Code 111
10
Teach-In function
11
Required accessories
12
Optional accessories
13
Ordering code
2
2
2
2
2
2
2
2
2
3
3
3
4
4
5
6
7
8
8
8
8
9
10
10
10
10
11
11
12
12
12
13
14
14
14
2012/02
Seite / page 1
