TF1 ユーザーズマニュアル / TF1 User manual
概要
1
安全上の注意
2
使用目的
2.1
2.2
インストールと起動
2.3
接続を確認する
システムの電源を入れる
2.4
測定値を確認する
2.5
機能を確認する
2.6
故障誤動作
2.7
3
電気的データ
4
配線手順
5
取付とインストール
5.1
トランスデューサー
5.2
ポジションマーカー
5.2.1
Z-TF1-P01
5.2.2
Z-TF1-P02
5.2.3
Z-TF1-P03
6
インターフェースと接続の割り当て
6.1
アナログ出力
6.2
SSI インターフェース
6.3
IO-Link インターフェース
6.4
CANopen インターフェース
6.5
ケーブル断線検出
7
ティーチイン機能
8
LED 機能
9
エラー状態
10
オプションのアクセサリ
11
注文コード
12
商品の識別
Page 1
2
1
2
2
2
2.1
2
2.2
2
2.3
2
2.4
2
2.5
2
2.6
2
2.7
3
3
3
4
4
5
4
5.1
5
5.2
5
5.2.1
5
5.2.2
5
5.2.3
6
6
6
6.1
6
6.2
7
6.3
7
6.4
8
6.5
8
7
10
8
10
9
11
10
11
11
11
12
General description
Safety instructions
Intended conditions of use
Installation & startup
Check connections
Turning on the system
Check measured values
Check functionality
Failure malfunction
Electrical data
Instructions for Wiring
Mounting and installation
Transducer
Position marker
Z-TF1-P01
Z-TF1-P02
Z-TF1-P03
Interfaces and Connection Assignment
Analog outputs
SSI interface
IO-Link interface
CANopen interface
Cable break detection
Teach-In function
LED Functionality
Error conditions
Optional accessories
Ordering code
Product identification
2
2
2
2
2
2
2
2
2
3
3
4
4
5
5
5
5
6
6
6
7
7
8
8
10
10
11
11
11

Advertisement

loading
Need help?

Need help?

Do you have a question about the Z-TF1-PO1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for novotechnik Z-TF1-PO1

  • Page 1 TF1 ユーザーズマニュアル / TF1 User manual 概要 General description 安全上の注意 Safety instructions 使用目的 Intended conditions of use インストールと起動 Installation & startup 接続を確認する Check connections システムの電源を入れる Turning on the system 測定値を確認する Check measured values 機能を確認する Check functionality 故障誤動作 Failure malfunction 電気的データ Electrical data 配線手順...
  • Page 2 TF1 ユーザーズマニュアル / TF1 User manual 1 General description 1 概要 The TF1 series is an inductive transducer for direct, TF1 シリーズは、制御、測定に用いられる高精度アブソリュートタイプの accurate measurement of travel in display- or feedback 誘導変位トランスデューサです。 applications. 2 Safety instructions 2 安全上の注意 Our products are regularly not approved for aeronautic or 当社の製品は、航空または航空宇宙用途では定期的に承認されておらず、原...
  • Page 3 TF1 ユーザーズマニュアル / TF1 User manual 3 電気的データ / Electrical data 供給電圧 /Supply voltage: 24 VDC ( データシートも参照 /see also data sheet) 消費電力 /Power consumption: ≤ 2.4 無負荷 /without load 負荷 / Load R : ≥ 5 ㏀ 電圧出力 / voltage output           ≤ 500Ω 電流出力 / current output 4 配線手順...
  • Page 4 TF1 ユーザーズマニュアル / TF1 User manual 5 インストール / Installation 5.1 トランスデューサ / Transducer 納品に含まれるもの:取り付けクランプ Z-46(ヘッドキャップネジ M5x20 を含む) Included in delivery: mounting clamps Z-46 incl. head cap screws M5x20 注文コードの例 必要なアクセサリ :ポジションマーカー 取り付けクランプを使用した取り付けの代わり に、トランスデューサーは、溝に挿入された M8 ナット (DIN 439、 厚さ 4.0 mm) で固定できます。 最大締付...
  • Page 5 TF1 ユーザーズマニュアル / TF1 User manual 5.2 ポジションマーカー 5.2 Position marker ポジションマーカー(アクセサリ)は、プロファイル面から定義された距離に The position marker (accessory) is installed at a defined distance to the profile surface . 設置します。トランスデューサの精度を確保するために、フローティングポジ In order to ensure the accuracy of the transducer, the floating position ションマーカーはプロファイル面と平行に設置する必要があります。...
  • Page 6 TF1 ユーザーズマニュアル / TF1 User manual 6 インターフェースと接続の割り当て / Interfaces and Connection Assignment 6.1 アナログ出力 / Analog Output ノイズを最小限に抑えるための推奨測定帯域幅 / Recomm. measuring bandwidth for noise reduction < 100kHz 注文コードの例 /Example ordering code: 電圧出力 / Voltage output: TF1- _ _ _ _ - _ _ _ -41_ - 102  注文コードの例...
  • Page 7 Example ordering code: TF1- _ _ _ _ - _ _ _ -A_ _ - 107 The description of IO-Link interface IO-Link インターフェースの説明 (…IO-Link_Detail) とデバイス説明ファイル (IODD) (…IO-Link_Detail) and the device description file は、Novotechnik の Web サイトからダウンロードできます。 ダウンロード / 操作マニュアルを参照してください (IODD) can be downloaded from => TF1 をクリックしてください。...
  • Page 8 TF1 ユーザーズマニュアル / TF1 User manual 6.5 ケーブル断線検出 / Cable break detection インターフェース / コード / ケーブル断線時の出力 / Interface Code Output at cable TF1-_ _ _ _ -_ _ _-2_ _-102 接続なし /no communication 0 …10 V TF1-_ _ _ _ -_ _ _-41_-102 <...
  • Page 9 TF1 ユーザーズマニュアル / TF1 User manual 2 ゼロポイントの設定 2 Setting up Zero Point 2a ポジションマーカーを使用して新しいプログラミング位置を起動します。 2a Start-up new programming position with the position marker. 2b ステータス LED の点滅が停止するまで PROG_L を GND へ(3…6 秒) 2b PROG_L on GND until Status-LED stops flashing(3…6 s) =>...
  • Page 10 速い赤点滅(チカチカと)/fast red flashing (flickering) etc. センサが動作中、CANopen:DS303-3 に準拠したバスの状態 Sensor in operation, CANopen: further bus status information according to DS303-3 オフ /OFF 赤 /Red センサエラー => Novotechnik サービス部門に連絡してください Sensor error => please contact Novotechnik service department オフ /OFF 黄 /yellow ユーザー設定データのセンサエラー(ティーチイン、CAN 設定 ...)=> 要確認 試運転前にセンサー設定を確認し、必要に応じて新しい構成を実行します...
  • Page 11 ポジションゲーバー / ポジションマーカー 11 注文コード /Ordering code 電気的測定範囲 電気接続 ミリ単位 コネクタ、8 ピン 機械的構成 電気的インターフェース コネクタ、5 ピン コネクタ、4 ピン プロファイルデザイン 電圧出力 電流出力 12 商品の識別 /Product Identification ネームプレート 注文コード バッチコード 連番 ■各種お問合せ ㈱ビー・アンド・プラス 〒 355-0311 埼玉県比企郡小川町高谷 2452-5 E-mail:NovotechnikJP@b-plus-kk.jp ㈱ビー・アンド・プラスは novotechnik 社の正規日本代理店です。 T621301Aj 2021.03.03 Page 11...
