oSiTioninG a ie
Proceed in the same manner as for Punch Adjustment.
S
Introducing a value equal to the half
of the table's width minus the half of
the tool length will place the tool in the
center of the machine (in our example:
3500/2 – 195/2 = 1652.5 mm).
A
pril
14/40 2016
V2.3
→ Tools position
Die placed in the middle
of the machine
i :
etting nStructionS
1. Touch the table (it will turn blue) to
select the die. The letter
next to the die name's selection field.
2. Touch the d field. The window to the
right is displayed.
3. Touch the desired die. Touch it a second
time to select it, or simply touch
c .
onFirM
4. Enter the tool's desired position in the
field.
5. Modify the L field by introducing
the value (here 195.00) which
corresponds to the required tool
length. In the front view the selected
tool appears in dark blue.
d is displayed
ModEva Pac User Manual
Die name
Die position
Die length
