G
eneral naviGaTion
The main navigation through the many different pages of the ModEva software is done by
mean of the buttons at the bottom of the screen.
The pages contain fields of different colors:

Menu Button

The
to products, tools or general machine parameters. When touching the
following pop-up window is displayed.

List of Products

Allows extracting
products stored in
the NC, in numerical
increasing order.
• The blues fields are fixed texts, such as category titles or headings.
• The gray fields, when touched, open a pop-up window with a list a choices.
• The black fields are those where data is to be entered.
• The khaki fields are information data fields, like real position of axes or actual value of
a variable.
Bend Button
Product Button
Menu Button
M button allows you to access programming pages, whether they are related
enu
List of Products

Graphical List of Products

Search of Product/Criteria
Transfer
Programming of Punches
Programming of Dies
Welcome
Machine Initialization DNC/ENC
Machine Parameters
Graphical List of Products
Allows extracting
products stored in
the NC, in numerical
order, and with the
graphic associated
to them.
Language
Correction Button
Actions Button
Shut Down Button
