TECHNICAL DATA

Table 13.1 - Technical Data
ZCF & ZCV
SUPPLY FAN
Fan Quantity
Fan Diameter
Fan Width
Standard Motor Size (Qty 1)
Standard Motor Type
Airflow (High/Medium/Low)
Max External Static Pressure
COIL WATER VOLUME
1 Row
2 Row
3 Row
4 Row
CONNECTIONS
Water Coils
Evaporator Coil
Steam Coil
Condensate Line
UNIT WEIGHT (approximate)
Shipping Weight
Operating Weight
FILTER
Quantity
Dimensions
Table 13.2 - Electrical Data
Motor Size
1/2 HP ECM Blower
1/2 HP ECM Blower, Condensate Pump
Units 750
2
8.06
7.15
hp 1/2
cfm 750/650/550
in.Wg 0.25
gal 0.32
gal 0.51
gal 0.72
gal 0.92
Inches
Inches
Inches
Inches
lbs. 375
lbs. 320
1
in. 10 X 36
115V
FLA MCA MOP FLA
7.7 9.6 15.0 5.0
9.2 11.1 15.0 5.6
AIR14-501.2
1000
Direct Drive Centrifugal
3
8.06
7.15
1/2
ECM - Electronically Commutated Motor
1000/850/750 1250/1100/1000
0.25
0.38
0.63
0.91
1.17
Unions with 3/4" female solder joint
3/4" OD Suction, 1/2" OD Liquid
1" NPT
3/4" ID condensate line
420
365
1" Woven Fiberglass, 70-75% Arrestance
2
10 X 24
208V 230V
MCA MOP FLA MCA
6.3 15.0 4.3 5.4
6.9 15.0 4.8 5.9
1250 1500
4 4
8.06 8.06
7.15 7.15
1/2 1/2
1500/1250/1000
0.25 0.25
0.44 0.5
0.76 0.88
1.1 1.28
1.42 1.66
470 520
410 450
2 2
10 X 30 10 X 36
277V
MOP FLA MCA MOP
15.0 4.1 5.1 15.0
15.0 4.6 5.6 15.0
13
