INSTALLATION GUIDE
November 2019 | 3725-86415-001A
Poly Medialign
GETTING HELP
For more information about installing, configuring, and
administering Poly/Polycom products or services, go to Polycom
Support.
Plantronics, Inc. (Poly – formerly Plantronics and Polycom)
345 Encinal Street
Santa Cruz, California
95060
© 2019 Plantronics, Inc. All rights reserved. Poly, the propeller
design, and the Poly logo are trademarks of Plantronics, Inc. All
other trademarks are the property of their respective owners.
