Electromagnetic Gate Lock
w/ Weldable Bracket
Mounting type
Manual
Face
1,200-lb (544kg)
Side
1,200-lb (544kg)
Face
• Water- and vandal-resistant attractive
stainless-steel finish
• Maintenance-free, factory-sealed design
• Fail-safe operation (releases if power is
removed)
• Mount vertically or horizontally
• Four knockouts on junction box
• Adapter and mounting hardware included
E-942FC-1K3SQ Shown
Holding force
600-lb (272kg)
*Maglock Only
Advertisement
Table of Contents
Related Manuals for SECO-LARM SLI E-942FC-1K3SQ
Summary of Contents for SECO-LARM SLI E-942FC-1K3SQ
- Page 1 Electromagnetic Gate Lock w/ Weldable Bracket Manual E-942FC-1K3SQ Shown Model Mounting type Holding force E-942FC-1K3SQ Face 1,200-lb (544kg) E-946FC-1K2SQ Side 1,200-lb (544kg) E-942FC-600SQ Face 600-lb (272kg) *Maglock Only • For most types of outdoor sliding and • Water- and vandal-resistant attractive swinging electric gates stainless-steel finish •...
