Amico AHM Installation And Adjustment Instructions

1. Monitor Mounting Adapter (Pg. 12-18)
Installation and Adjustment Instructions
VESA LCD mount shown, other options available
2. Monitor Head - Rotation (Pg. 22)
Monitor Rotation Adjustment
Quick Setup
3. Height Locking Lever (Pg. 25)
Adjustable Height Monitor (AHM) Arm
Locks the arm at a desired height
4. Counter Balance (Pg. 27)
Used to adjust for zero movement.
5. Extension Arm (Pg. 26) It is the responsibility of the end user to ensure all aspects of the installation are covered by following the full manual at:
http://www.amico.com/pdf/accessories/AHM_Manual.pdf
6'' extension arm shown
6.Mounting Adapter (Pg. 6-10)
MON adapter shown for MRS rail
Installation Tools & Reference
7. Monitor Head - Tilt (Pg. 21)
Tilt Adjustment Handle
AHM MONITOR ARM
8. Cable Management (Pg. 29)
1 Monitor Mounting Adapter
Manages the cables of the Monitor
VESA LCD mount shown, other options available
for better organization.
2 Monitor Head - Rotation
Monitor Rotation Adjustment
3 Monitor Locking Lever
Locks the arm at a desired height
4 Counter Balance
Used to adjust for zero movement
*
5 Extension Arm
6" extension arm shown
6 Mounting Adapter
MON adapter shown for MRS rail
7 Monitor Head - Tilt
Tilt Adjustment Handle
8 Cable Management
Manages the cables for better organization
*
If requested
1. Installation to Structure
4 x 1/4-20 Set screws
Use 1/8" (3mm) hex key
to tighten
*WARNING: Never attempt to mount or remove the arm from the rail when a monitor is installed.
*WARNING: Support AHM arm until the set screws are tightened, AHM arm can slide down when
set screws are not tightened.
Toll Free Tel: 1.877.264.2697 l Tel: 905.763.7778
Fax: 905.763.8587
Medical Facility Responsibility
7
7
8
1
2
3
4
5
6
2. Installation to Monitor
Insert screws through M4 holes
into back of monitor (4x)
*
*
LCD mount shown, for other monitor styles, refer to manual.
**
Hex key (1/8", 3/16", M3, M4) - 1
Philips screw driver
Socket wrench (12mm, 1/2") - 1
Adjustable wrench
**
Not provided by Amico
