Transport

4
Packages can be handled with a lifting hook or pallet truck of suitable capacity. The choice of the
most suitable means and method lies with the operator.
The operating area must be perfectly free from objects or people not involved in the transport.
If the unit is moved using hooks, use some spreader bars between the lifting cables to prevent
damage to the unit and ensure no excessive stress is placed on the side panels.

Lifting using hooks

Use hooks with a capacity adequate to the weight of the package to be lifted. Make sure that the safety
latch is in the correct position while lifting.
DO NOT move the equipment if the field of vision is poor or there are obstacles along the way (e.g.,
electric cables, beams, etc.). When the loads are lifted, the range of action of the lifting equipment
must remain free of persons.
Use perfectly serviceable hooks, chains or steel cables of adequate capacity and material, with-
out any joints or extensions. To guarantee efficiency, carry out periodic checks.
Make sure the ground the lifting equipment rests on is stable and not subject to subsidence. Check
the flatness of the ground. Do not move the lifting device with the machine suspended in the air.
Before lifting it, check the position of the centre of gravity and that the equipment is correctly
anchored to the lifting points provided, then slowly lift the package to the minimum height
necessary and move it carefully to prevent any dangerous vibrations.
Avoid sudden stops while lifting or lowering the package, to prevent any dangerous oscillations.
OK!
OK!
