Installation procedure

Before installation, read the safety instructions on the first pages of this manual. Contact the Manufac-

turer if any points are unclear or not perfectly understandable. A check mark next to each step will help

to confirm complete and proper installation.

Step 1: Position the unit ....................................................................................................................................................page 31

Step 2: Assemble the unit (if necessary) .................................................................................................................page 32

Step 3: Fasten the units to the ground (optional) ............................................................................................page 35

Step 4: Make the connections ......................................................................................................................................page 36

Step 5: Perform a trial run ................................................................................................................................................page 48

Step 6: Install the required filters .................................................................................................................................page 49

Step 7: Safety signs ...............................................................................................................................................................page 50

After installation store this manual and the assembly sheet that accompanied the machine in a place

that is dry and clean. This way it will be accessible to operators in the future who need to consult it.

Do not remove, tear out or write on any part of this manual besides the space set aside for notes:

Installer/maintenance notes
