Specialized TARMAC SL7 User Manual page 11

PART # DESCRIPTION
A FRAME
B FORK
C
S201900003 FRONT DERAILLEUR (FD) HANGER
D S201900002 RUBBER FD BLOCK OFF PLATE
E S182600001 REAR DERAILLEUR (RD) HANGER
F S204900002 SEATPOST WEDGE
G S204900003 SEATPOST WEDGE COVER
H SEATPOST (SADDLE CLAMP)
I S199900003 Di2 BATTERY GROMMET
J S180200004 FRONT AXLE
K S180200005 REAR AXLE
L WATER BOTTLE
M SEATPOST Di2 JCT A BOX (20mm)
S209900058
N SEATPOST HOLE COVER (20mm)
M SEATPOST Di2 JCT A BOX (0mm)
S209900057
N SEATPOST HOLE COVER (0mm)
O S179900013 CABLE HOUSING FERRULE
P S189900021 BOTTOM BRACKET RUBBER COVER
Q S149900018 STEM TOP CAP
Many bolts have a blue threadlock patch on the threads to help secure the bolt under torque. Repeated installation and removal of a bolt may reduce the effectiveness of
the patch. However, it can be replaced with the application of a liquid blue threadlocker.
TOOL SIZE in-lbf Nm
2.5mm 18 2.0
4mm 40 4.5
4mm 55 6.2
5mm 120 13.5
6mm 133 15
6mm 133 15
3mm 25 2.8
2.5mm 7 0.8
2.5mm 7 0.8
2.5mm 7 0.8
2.5mm 7 0.8
4mm
PART # DESCRIPTION
R STEM FACEPLATE
S S204800003 STEM CABLE BAT
T
STEM COVER (OPEN)
U STEM COVER (CLOSED)
V UPPER TRANSITION
W 5mm SPACER
S202500009
X 10mm SPACER
Y LOWER TRANSITION (ELECTRONIC)
Z LOWER TRANSITION (MECHANICAL)
AA LOWER TRANSITION (NON-AERO)
BB S202500008 COMPRESSION RING
CC S162500005 HEADSET BEARING
DD ACCESSORY MOUNT @ FACEPLATE
EE S189900104 ACCESSORY MOUNT @ CAMERA
FF ACCESSORY MOUNT @ COMPUTER
GG S142500007 EXPANSION PLUG
HH SEE FIG. 1 REAR DERAILLEUR PLUG
I I SEE FIG. 1 FRONT DERAILLEUR PLUG
NOT SHOWN HANDLEBAR CLIPS
TOOL SIZE in-lbf Nm
4mm 44 5.0
3mm 26.5 3.0
3mm 24 2.7
3mm 9 1.0
2.5mm 9 1.0
6mm 80 9.0
2.5mm 9 1.0
