  • Page 1 USER MANUAL...

  • Page 3: Table Of Contents

    10. SMALL PARTS ........................23 SPECIALIZED BICYCLE COMPONENTS 15130 Concord Circle, Morgan Hill, CA 95037 (408) 779-6229 0000097877_UM_R1, 12/17 Please note all instructions are subject to change and updates without notice. Please visit www.specialized.com for periodic tech updates. Feedback: techdocs@specialized.com...

  • Page 4: Introduction

    TECH TIP: Tech Tips are useful tips and tricks regarding installation and use. 1.1. INTENDED USE The Stumpjumper FSR bicycles are intended and tested for Mountain Bike (condition 4) use only. For more information on intended use and structural weight limits for the frame and components, please refer to the Owner’s Manual.

  • Page 5: Fork/Headset/Stem

    Stumpjumper FSR specific components should only be used on the Stumpjumper FSR and not on other bicycles, even if they fit. Failure to follow this warning could result in serious injury or death.

  • Page 6: Bottom Bracket

    Please visit your Specialized Authorized Retailer for additional information. 2.3. BOTTOM BRACKET Stumpjumper FSR models have a threaded 73mm width bottom bracket shell and is compatible with any BSA threaded outboard bearing bottom bracket. Please refer to the crank manufacturer documentation for bottom bracket compatibility.

  • Page 7: General Notes About Maintenance

    The surfaces of the bicycle should be cleaned before each ride. The bicycle should also be maintained regularly by an Authorized Specialized Retailer, which means it should be cleaned, inspected for signs of corrosion and/ or cracks and lubricated. If you notice any signs of corrosion or cracking on the frame or any component, the affected item must be replaced.

  • Page 8: Specifications

    4.2. FRAME/BIKE CUSTOMIZATION: Stumpjumper FSR frames are available in two frame types (29” or 27.5”), each of which is available in two stock configurations (SJ ST and SJ), with different wheel/tire, shock, shock extension and/or fork options. Each of these variables will affect the bottom bracket height and head angle of the frame, as well as the general ride characteristics of the bike.

  • Page 9: Tools Required

    WARNING! While the 29 frame is generally compatible with tires up to 27.5 x 3.0 or 29 x 2.6 and the 27.5 frame with tires up to 27.5 x 3.0, tire dimensions can vary depending on the manufacturer, and not all forks are designed to accept a larger tire. Always check with the fork manufacturer regarding required clearances.

  • Page 10: Rear Triangle Pivot Assembly

    4.5. REAR TRIANGLE PIVOT ASSEMBLY In order to successfully build the Stumpjumper FSR rear triangle, it is very important to follow the order of operations as outlined in this manual. Modifying the order of assembly will result in a longer build process.
  • Page 11 2. LINK @ SEAT TUBE Grease, then place the spacers against the inner surface of the link @ seat tube bearings (tapered surface „ against bearing). Align the link with the seat tube pivot, then insert the pivot bolts. „ Place a small rag between the link and seat tube to prevent any damage to the seat tube.
  • Page 12 4. EXTENSION @ LINK Align the extension with the bearings, then insert the pivot bolts. „ 5. HORST LINK (DROPOUT) CARBON FRAME: Ensure the housing guide tubes are installed in the chainstay before assembling the rear triangle to the frame. Refer to section 5.2, page 13 for internal cable routing instructions.
  • Page 13 6. SEATSTAY @ LINK Grease, then place the two outer dropout spacers against the link bearings (tapered surface against bearing). „ AIign the seatstay tabs with the link pivot bearings and spacers, then insert the pivot bolts. „ 7. MAIN (BOTTOM BRACKET) Guide the housing tubes through the rubber boot and routing port behind the main pivot according to the internal „...
  • Page 14 Insert the drive side and non-drive side bolts into their respective sides (drive side bolt tightens counter-clockwise). „ 8. LOWER SHOCK EYE BOLT Once all pivot locations are assembled and torqued to specification, torque the lower shock eye bolt. „ TECH TIP: For easy lower shock eye bolt access, use the Carbon Crank 6mm Allen w/Socket, part #9891-3010.

  • Page 15: Internal Routing (Carbon Frame)

    5. INTERNAL ROUTING (CARBON FRAME) 5.1. DROPPER SEATPOST To simplify assembly, always install the seatpost housing before the shift and brake housings. Make sure the SWAT latch and dropper post plastic tube are installed in the frame before routing the dropper housing. MOLDED TUBE SHIFT...

  • Page 16: Shift/Brake

    5.2. SHIFT/BRAKE INSERT 4-5mm OD CENTER PUNCH FINISH FINISH START Before starting this process, the link and shock should be assembled to the frame (see section 4.4). „ Route the rear brake internal routing tube through the chainstay, starting at the non-drive side main pivot hole. „...
  • Page 17 MARK Install the rubber boot into the routing port behind the main pivot. „ Guide the tubes up through the side-arm, top tube, then out the bottom of the head tube. „ Align the chainstay bearings and spacers with the main pivot location of the frame, then loosely install the bolts. „...
  • Page 18 Once both tubes are bottomed out against the lip of the exit port holes, install a set screw and thread it in until it „ is flush with the exit port. Press on the inside of the tube against the set screw to seat the tubes (see fig.7 inset). Gently pull any excess tube out of frame from the chainstay ports.
  • Page 19 PRESS ONTO THREADS Push the tube back in until it is flush with the exit port, then install a set screw until it is also flush with the exit port. „ Repeat the process for the shift tube. „ After the set screws are installed, place the punch inside each tube and use the punch to press the tube down on „...

  • Page 20: Internal Routing (Alloy Frame)

    6. INTERNAL ROUTING (ALLOY FRAME) 6.1. DROPPER SEATPOST To simplify assembly, always install the seatpost housing before the shift and brake housings. Remove the plastic shift/brake port behind the bottom bracket before routing the seatpost housing through the „ frame. Before removing the shift/brake port from behind the bottom bracket, the chainstay must be removed from the front triangle.

  • Page 21: Shift/Brake

    6.2. SHIFT/BRAKE To install the chainstay housing guide, insert the locating tab into the non-drive side of the chainstay bridge cavity, „ then pop it down so that it is flush with the bridge. Next, install the locator bolt until it bottoms out. Do not overtighten. Make sure your brake and shift housings are long enough to reach all the way to the handlebar controls.
  • Page 22 Install the brake and shift mechanisms according to the manufacturer’s instructions. „ Position the seatstay brake housing clip so that it is perpendicular to the tube and the housing is below/behind „ the bolt. Position the chainstay clip so the housing is below the bolt and positioned horizontally. Ensure that the housing has a natural loop (curvature) between the seatstay and chainstay.

  • Page 23: Swat Bike Equipment

    7. SWAT BIKE EQUIPMENT Stumpjumper FSR frames are compatible with certain SWAT (Storage, Water, Air, Tools) components. SWAT components are listed below: 7.1. SWAT CC The SWAT CC (Conceal Carry) tool includes the top cap, chain tool and custom EMT mini tool that fits inside „...
  • Page 24 Fold tube over twice Insert tube Roll up into pockets SWAT wrap Too loose Correct tightness C02 x 2 + head AIRTOOL MTB DB Pump...

  • Page 25: Air Shock Setup

    CAUTION: Do not exceed the shock manufacturer’s maximum pressure (FOX: 350psi, RockShox: 325psi, X-Fusion: 250psi). Please visit the suspension setup tool at www.specialized.com for personalized recommendations for a baseline suspension setup based upon your specific height and weight. 8.2. ADJUSTING REBOUND Rebound damping (red knob) controls the rate at which the shock returns after it has been compressed.

  • Page 26: Setup Data

    9. SETUP DATA DATE RIDER WEIGHT FORK PSI FORK REBOUND (# of clicks from full slow) FORK COMPRESSION (# of clicks from full firm) SHOCK PSI SHOCK REBOUND (# of clicks from full slow) SHOCK COMPRESSION (# of clicks from full firm) 10.

  • Page 28: Specialized Bicycle Components
