Dakota Digital VHX-68O-CUT Instrument Installation

For 1968-69 oldsmobile cutlass

Your new VHX-68O-CUT kit includes:

Universal Sender Pack

Switch Assembly

(2) 36" CAT5 Cable

(1) 12" CAT5 Cable

Installation

1. First, remove the stock gauges from the dash by removing the two (2) mounting screws on the back

side of each gauge. Retain all factory hardware for reassembly.

VHX-68O-CUT

Dakota Digital VHX Instrument Installation

For 1968-`69 Oldsmobile Cutlass

Installation Manuals

VHX Display

Control Box

Manual # 650648

Table of Contents

Do you have a question about the VHX-68O-CUT and is the answer not in the manual?

Page 1 VHX-68O-CUT Dakota Digital VHX Instrument Installation For 1968-`69 Oldsmobile Cutlass Your new VHX-68O-CUT kit includes: Universal Sender Pack VHX Display Installation Manuals Control Box Switch Assembly (2) 36” CAT5 Cable (1) 12” CAT5 Cable Installation 1. First, remove the stock gauges from the dash by removing the two (2) mounting screws on the back side of each gauge.
Page 2 2. Remove each of the three (3) factory gauge bezels and mount them to the VHX system using the four (4) original screws per gauge. 3. Mount the VHX system to the stock dash using the stock screws from disassembly. tach speed quad...
Page 3 5. Refer to the main manual for wiring instructions to complete the VHX installation. WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov Manual # 650648...
