Parts List - Icom IC-R30 Service Manual

SECTION 5
[LOGIC UNIT] (for #12 and #20)
REF PART
NO. NO.
IC1 1110007780 S.IC NJU7704F3-28A-TE1-#ZZZH
IC2 1180005080 S.REG LP5907MFX-3.0/NOPB
IC3 1130014260 S.IC SN74LVC2GU04DCKR
IC4 1140017920 S.IC R5F564MLDDBG
IC5 1140017190 S.IC GT24C1024-2CLI-TR
IC6 1140017190 S.IC GT24C1024-2CLI-TR
IC9 1130017182 S.IC RMLV0416EGBG-4S2
IC10 1130018740 S.IC RX8130CE
IC11 1130015760 S.IC TC74VHC4066AFK (EK)
IC12 1130014260 S.IC SN74LVC2GU04DCKR
IC13 1110009520 S.IC TMP303BDRLR
IC14 1180005080 S.REG LP5907MFX-3.0/NOPB
IC15 1130015820 S.IC SN74AUP1T17DCKR
IC16 1190004620 S.IC GSU-141A-098A (CXD5431-06)
IC17 1130017400 S.IC MC74HC4094ADTR2G
IC18 1130017400 S.IC MC74HC4094ADTR2G
IC19 1130017400 S.IC MC74HC4094ADTR2G
IC20 1180004380 S.REG TLV70030DCKR
IC21 1190004711 S.IC HRM1016-010021 (EX3873A1)
IC22 1130007021 S.IC TC7S66FU (TE85LF)
IC23 1130018860 S.IC SN74AC00PWR
IC24 1180004380 S.REG TLV70030DCKR
IC25 1190004530 S.IC MAX14656EWE+T
IC200 1140016370 S.IC TMS320C5517AZCHA20
IC201 1130016670 S.IC IS61WV12816DBLL-10BLI
IC202 1130017750 S.IC EN25Q40A-104XIP
IC203 1130018150 S.IC SN74AUP1T04DCKR
IC204 1130018620 S.IC AK4555VT5P-E2/P
IC205 1180004380 S.REG TLV70030DCKR
IC206 6910022370 S.DC TPS62400DRCR
IC208 1110008940 S.IC NJU7057RB1-TE2-#ZMZH
IC209 1110008830 S.IC NJU7058V-TE2-#ZMZH
IC210 1130009981 S.IC TC7W53FK (TE85LF)
Q1 1560002190 S.FET RUM002N02T2L
Q2 1590004690 S.TRA LDTC143ZET1G
Q3 1510001100 S.TRA 2SA1832-GR (TE85RF)
Q4 1590004070 S.TRA LDTC144EET1G
Q5 1530003990 S.TRA 2SC4738-BL (TE85LF)
Q6 1510001100 S.TRA 2SA1832-GR (TE85RF)
Q7 1590004070 S.TRA LDTC144EET1G
Q8 1560002190 S.FET RUM002N02T2L
Q9 1590004070 S.TRA LDTC144EET1G
Q10 1510001100 S.TRA 2SA1832-GR (TE85RF)
Q11 1590004070 S.TRA LDTC144EET1G
Q12 1590004070 S.TRA LDTC144EET1G
Q13 1590004070 S.TRA LDTC144EET1G
Q14 1590004070 S.TRA LDTC144EET1G
Q15 1590004070 S.TRA LDTC144EET1G
Q16 1590004040 S.TRA LDTA123YET1G
Q17 1550000400 S.FET SSM3J15FS (TE85LF) Only [#12] T
Q200 1590004070 S.TRA LDTC144EET1G
Q201 1590004070 S.TRA LDTC144EET1G
Q202 1510001100 S.TRA 2SA1832-GR (TE85RF)
D1 1790001960 S.VAR VC060303A100RP
D4 1750001810 S.DIO L1SS400T1G
D6 1750001810 S.DIO L1SS400T1G
D7 1750001810 S.DIO L1SS400T1G
D14 1750001810 S.DIO L1SS400T1G
D15 1750001810 S.DIO L1SS400T1G
D17 1750001810 S.DIO L1SS400T1G
D19 1750001810 S.DIO L1SS400T1G
D21 1750001810 S.DIO L1SS400T1G
D22 1750001810 S.DIO L1SS400T1G
D23 1750001810 S.DIO L1SS400T1G
D24 1750001810 S.DIO L1SS400T1G
D25 1750001810 S.DIO L1SS400T1G
D26 1750001810 S.DIO L1SS400T1G
D27 1750001810 S.DIO L1SS400T1G
D36 1750002540 S.DIO LRB520G-30T1G
X1 6090000060 S.E.O SIT9005AIL21-30DH24.000000E
X200 6050013981 S.XTA CR-997A (12.288 MHz)
L1 6200013850 S.COI MLK1005S15NJT
L200 6200014260 S.COI LQM2MPN2R2NG0L
L201 6200014260 S.COI LQM2MPN2R2NG0L
L202 6200014260 S.COI LQM2MPN2R2NG0L
R1 7030016160 S.RES RMC1/16S-820JTH (82)
R2 7030016160 S.RES RMC1/16S-820JTH (82)
R3 7030016160 S.RES RMC1/16S-820JTH (82)
R4 7030016460 S.RES RMC1/16S-181JTH (180)
R5 7030016270 S.RES RMC1/16S-151JTH (150)
R6 7030016020 S.RES RMC1/16S-104JTH (100K)
R7 7030015970 S.RES RMC1/16S-103JTH (10K)
R8 7030015970 S.RES RMC1/16S-103JTH (10K)
R9 7030015970 S.RES RMC1/16S-103JTH (10K)
R10 7030015970 S.RES RMC1/16S-103JTH (10K)
R11 7030016110 S.RES RMC1/16S-473JTH (47K)
R12 7030015970 S.RES RMC1/16S-103JTH (10K)
R13 7030015970 S.RES RMC1/16S-103JTH (10K)
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.

PARTS LIST

DESCRIPTION M.
LOCATION
B 41.9/45.1
T
B 52.0/41.4
B 60.3/30.7
B 52.3/33.4
B 52.3/36.1
B 75.5/28.5
T 82.8/18.5
B 48.3/23.1
B 57.6/43.4
Only [#12] T 86.9/21.5
B 93.8/38.0
B
B
B 63.1/15.3
B 68.7/15.3
B 74.3/15.3
B 90.7/35.7
T 85.3/35.7
T 93.5/37.6
B 41.1/41.1
B 90.6/39.9
B 57.9/39.4
B 26.0/26.6
B 36.0/25.6
B 39.0/11.5
B 32.0/34.3
B 16.4/27.9
B 36.7/44.9
B 87.7/26.5
B 29.0/41.9
B 55.6/15.3
B 46.6/13.0
B
B 60.3/10.2
B 54.3/43.6
B 47.0/39.4
B 49.1/39.6
B 60.9/43.9
B 49.4/26.9
B 54.6/45.5
B
B
T 77.7/39.8
T 95.8/40.6
T 93.3/40.8
T 84.9/22.9
T 90.4/10.9
T 90.4/12.9
86.9/19.1
B 35.7/31.6
B 46.5/30.7
B 47.1/33.6
B 64.4/10.0
B 54.8/40.2
B 57.4/45.5
T 82.8/21.0
Only [#20] B
Only [#20] B
Only [#20] B
B 73.1/10.6
B 75.6/10.6
B
B
B
T 75.5/14.8
T 75.5/16.0
T 73.0/14.8
B 47.5/42.7
B 50.1/30.1
B 37.7/33.7
T 92.7/28.7
B 90.5/24.0
B 84.9/24.0
B 84.2/30.3
T 64.4/10.7
T 64.4/21.7
T 64.4/32.7
B
B
B
B 50.4/45.6
B 49.5/45.6
B 48.6/45.6
B 47.7/45.6
B 93.5/10.6
B 47.7/44.0
B 48.6/44.0
[LOGIC UNIT] (for #12 and #20)
H/V REF PART
NO. NO.
R14 7030016110 S.RES RMC1/16S-473JTH (47K)
93.1/3.4 R15 7030016110 S.RES RMC1/16S-473JTH (47K)
R16 7030015970 S.RES RMC1/16S-103JTH (10K)
R17 7030015970 S.RES RMC1/16S-103JTH (10K)
R18 7030016110 S.RES RMC1/16S-473JTH (47K)
R19 7030015970 S.RES RMC1/16S-103JTH (10K)
R20 7030016110 S.RES RMC1/16S-473JTH (47K)
R21 7030016110 S.RES RMC1/16S-473JTH (47K)
R22 7030016110 S.RES RMC1/16S-473JTH (47K)
R26 7030016560 S.RES RMC1/16SJPTH
R27 7030016560 S.RES RMC1/16SJPTH
R28 7030016560 S.RES RMC1/16SJPTH
30.5/4.3 R29 7030016560 S.RES RMC1/16SJPTH
19.8/8.8 R30 7030016560 S.RES RMC1/16SJPTH
R31 7030016560 S.RES RMC1/16SJPTH
R37 7030016020 S.RES RMC1/16S-104JTH (100K)
R38 7030016020 S.RES RMC1/16S-104JTH (100K)
R40 7030016050 S.RES RMC1/16S-102JTH (1K)
R41 7030016050 S.RES RMC1/16S-102JTH (1K)
R42 7030016090 S.RES RMC1/16S-223JTH (22K)
R43 7030016090 S.RES RMC1/16S-223JTH (22K)
R44 7030016050 S.RES RMC1/16S-102JTH (1K)
R45 7030016050 S.RES RMC1/16S-102JTH (1K)
R47 7030016110 S.RES RMC1/16S-473JTH (47K)
R48 7030015970 S.RES RMC1/16S-103JTH (10K)
R50 7030016380 S.RES RMC1/16S-183JTH (18K)
R51 7030016020 S.RES RMC1/16S-104JTH (100K)
R52 7030016110 S.RES RMC1/16S-473JTH (47K)
R53 7030016050 S.RES RMC1/16S-102JTH (1K)
R54 7030016360 S.RES RMC1/16S-123JTH (12K)
R55 7030016110 S.RES RMC1/16S-473JTH (47K)
R56 7030016110 S.RES RMC1/16S-473JTH (47K)
R57 7030016110 S.RES RMC1/16S-473JTH (47K)
R58 7030016020 S.RES RMC1/16S-104JTH (100K)
R59 7030016020 S.RES RMC1/16S-104JTH (100K)
60.3/8.2 R60 7030016110 S.RES RMC1/16S-473JTH (47K)
R61 7030016290 S.RES RMC1/16S-222JTH (2.2K)
R62 7030016020 S.RES RMC1/16S-104JTH (100K)
R63 7030016050 S.RES RMC1/16S-102JTH (1K)
R64 7030016050 S.RES RMC1/16S-102JTH (1K)
R65 7030016050 S.RES RMC1/16S-102JTH (1K)
R66 7030016050 S.RES RMC1/16S-102JTH (1K)
R67 7030016050 S.RES RMC1/16S-102JTH (1K)
21.8/3.8 R68 7030016050 S.RES RMC1/16S-102JTH (1K)
17.9/3.8 R69 7030016050 S.RES RMC1/16S-102JTH (1K)
R71 7030016060 S.RES RMC1/16S-105JTH (1M)
R73 7410001140 S.ARR EXB28V104JX
R74 7410001140 S.ARR EXB28V104JX
R75 7030016050 S.RES RMC1/16S-102JTH (1K)
R76 7030016050 S.RES RMC1/16S-102JTH (1K)
R77 7030016110 S.RES RMC1/16S-473JTH (47K)
R78 7030016290 S.RES RMC1/16S-222JTH (2.2K)
R79 7510001770 S.THE NTCG10 4LH 473JT
R80 7030016020 S.RES RMC1/16S-104JTH (100K)
R81 7030016110 S.RES RMC1/16S-473JTH (47K)
R82 7030015970 S.RES RMC1/16S-103JTH (10K)
R83 7030016020 S.RES RMC1/16S-104JTH (100K)
R84 7030015970 S.RES RMC1/16S-103JTH (10K)
R85 7030016380 S.RES RMC1/16S-183JTH (18K)
R86 7410001140 S.ARR EXB28V104JX
R87 7030016560 S.RES RMC1/16SJPTH
73.1/8.2 R88 7030016020 S.RES RMC1/16S-104JTH (100K)
73.1/7.0 R89 7030016020 S.RES RMC1/16S-104JTH (100K)
73.1/9.4 R90 7410001140 S.ARR EXB28V104JX
R91 7030016290 S.RES RMC1/16S-222JTH (2.2K)
R92 7030016020 S.RES RMC1/16S-104JTH (100K)
75.6/9.4 R95 7030016020 S.RES RMC1/16S-104JTH (100K)
75.6/7.0 R96 7030016110 S.RES RMC1/16S-473JTH (47K)
75.6/8.2 R98 7030016020 S.RES RMC1/16S-104JTH (100K)
R99 7030016020 S.RES RMC1/16S-104JTH (100K)
R101 7030015970 S.RES RMC1/16S-103JTH (10K)
R102 7030016020 S.RES RMC1/16S-104JTH (100K)
R103 7030016020 S.RES RMC1/16S-104JTH (100K)
R104 7030016020 S.RES RMC1/16S-104JTH (100K)
R105 7030016110 S.RES RMC1/16S-473JTH (47K)
R106 7030016110 S.RES RMC1/16S-473JTH (47K)
R107 7030016110 S.RES RMC1/16S-473JTH (47K)
R108 7030016110 S.RES RMC1/16S-473JTH (47K)
R109 7030016110 S.RES RMC1/16S-473JTH (47K)
R110 7030016560 S.RES RMC1/16SJPTH
R111 7030016560 S.RES RMC1/16SJPTH
R114 7030015910 S.RES RMC1/16S-101JTH (100)
R115 7030015970 S.RES RMC1/16S-103JTH (10K)
R116 7030016290 S.RES RMC1/16S-222JTH (2.2K)
R117 7030015970 S.RES RMC1/16S-103JTH (10K)
R120 7030016090 S.RES RMC1/16S-223JTH (22K)
R121 7030015970 S.RES RMC1/16S-103JTH (10K)
R123 7030016020 S.RES RMC1/16S-104JTH (100K)
61.8/9.6 R124 7030016110 S.RES RMC1/16S-473JTH (47K)
62.7/9.6 R125 7030016280 S.RES RMC1/16S-331JTH (330)
60.3/6.8 R126 7030016560 S.RES RMC1/16SJPTH
R127 7030016050 S.RES RMC1/16S-102JTH (1K)
R128 7030016560 S.RES RMC1/16SJPTH
R129 7030016560 S.RES RMC1/16SJPTH
R130 7030016560 S.RES RMC1/16SJPTH
R131 7030016560 S.RES RMC1/16SJPTH
R132 7030015900 S.RES RMC1/16S-470JTH (47)
R133 7030015900 S.RES RMC1/16S-470JTH (47)
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-1
DESCRIPTION M.
LOCATION
T
T
B 52.2/45.6
B 46.8/45.6
T
B 51.3/45.6
T
T
T
T
T
T
T
T
T
B 50.2/41.7
B 52.5/39.6
B 53.8/10.0
B 57.8/21.7
B
B 57.5/23.5
B
B 56.3/23.2
B 52.4/44.3
B 54.3/42.1
B 54.3/41.2
B 51.1/26.8
B 46.1/36.1
B 47.6/27.4
B 50.9/39.6
B 52.8/27.7
B 46.1/37.0
B 52.8/25.9
B 55.9/38.7
B 54.3/38.7
B 47.8/37.0
B 47.8/36.1
B 61.4/38.7
B 45.5/22.0
B 61.0/20.8
B 52.8/25.0
B 45.5/25.2
B 67.8/33.8
B 67.8/28.1
B 67.8/29.2
B 67.8/30.1
B 80.4/26.9
B 80.4/29.8
B 67.8/31.9
B 67.8/32.8
T 80.4/19.9
T 85.2/18.7
B 51.5/22.3
B 51.0/23.5
T 85.2/17.8
B 59.4/42.7
B 51.4/20.8
B 61.1/45.5
B 59.5/45.5
B 70.7/26.9
B 55.9/44.4
B 47.6/26.3
T 85.2/16.7
B 70.7/30.6
B 59.4/44.3
B
B
B
B
B 76.0/20.2
B
T 77.7/41.3
T 97.3/40.3
B 67.5/36.7
T 75.7/40.4
T 75.7/41.3
T 77.9/36.6
T 77.9/35.7
B 72.2/38.5
B 78.9/34.7
B 78.0/34.7
T 92.9/35.8
T 92.9/34.0
T 92.7/27.8
T 83.4/23.0
T 92.7/29.6
T 95.4/38.1
B 89.8/37.7
T 70.5/13.5
T 86.8/12.8
B
B 44.2/44.2
T 78.0/23.7
T 70.5/31.4
T 70.5/29.6
T 85.2/19.6
T 70.5/33.2
T 70.5/32.3
H/V
90.1/2.7
89.0/2.7
86.8/2.7
84.6/2.7
83.5/2.7
82.4/2.7
90.1/4.3
89.0/4.3
86.8/4.3
85.5/3.4
83.9/3.9
82.4/4.3
49.5/7.2
54.8/5.5
29.6/7.0
31.4/7.0
26.9/3.8
19.8/3.2
19.8/4.2
13.6/8.3
