INTRODUCTION
This service manual describes the latest service information
for the FP-561 MARINE PLOTTER/SOUNDER and RD-200
DGPS BEACON RECEIVER at the time of publication.
MODEL VERSION
General
FP-561
Europe
To upgrade quality, all electrical or mechanical parts and
internal circuits are subject to change without notice or
obligation.

ORDERING PARTS

Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
0910051392 PCB B-5305
8810004540 Screw BiH 3x8 SUS
Addresses are provided on the inside back cover for your
convenience.
fineline6
SYMBOL
GEN
EUR
FP-561
FP-561 MAIN UNIT 1 pieces
FP-561 Chassis 10 pieces
DANGER
NEVER connect the unit to an AC outlet or to a DC power
supply that uses more than 33 V (FP-561) or 16 V (RD-200).
Such a connection could cause a fire hazard and/or electric.
DO NOT expose the unit to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the unit.
DO NOT apply an RF signal of more than 20 dBm (100mW)
to the antenna connector. This could damage the unit's front
end.

REPAIR NOTES

1. Make sure a problem is internal before disassembling
the unit.
2. DO NOT open the unit until the unit is disconnected from
its power source.
3. DO NOT force any of the variable components. Turn
them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insulat-
ed turning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the unit is
defective.
6. READ the instructions of test equipment thoroughly
before connecting equipment to the unit.
RD-200
