4-2 ADJUSTMENT (CONTINUED)
ADJUSTMENT
ITEM
Noise 42 A NSQL
squelch 43 A NSQL
44 A NSQL
45 A NSQL
46 A NSQL
47 B NSQL
48 A NSQL
49 B NSQL
50 A NSQL
51 B NSQL
52 A NSQL
53 B NSQL
54 A NSQL
55 A NSQL
56 A NSQL
ADJUSTMENT DISPLAY
FREQUENCY MODE
22.500 FM
40.100 FM
63.100 FM
92.100 FM
145.100 FM
145.100 FM
217.100 FM
217.100 FM
320.100 FM
320.100 FM
470.100 FM
470.100 FM
650.100 FM
1167.500 FM
2341.100 FM
SETTING CONDITION
SUB
145.100 Set the standard signal generator to:
145.100 Frequency:
145.100
145.100
Modulation:
145.100
Deviation:
145.100
Level:
217.100
217.100
320.100
320.100
470.100
470.100
145.100
145.100
145.100 Set the standard signal generator to:
Level:
4-4
The same as the displayed
frequency on the MAIN band.
1 kHz
±3.5 kHz
–26 dBµ (–133 dBm)
–22 dBµ (–129 dBm)
VALUE
Push
[ENTER].
(Automatic
adjustment)
