Icom IC-R30 Service Manual page 2

INTRODUCTION
This service manual describes the latest technical
information for the IC-R30 COMMUNICATIONS
RECEIVER at the time of publication.
VERSION
MODEL VERSION
NUMBER
EUR-01 #12
IC-R30 USA-01 #16
USA-02 #20
To upgrade quality, any electrical or mechanical parts and
internal circuits are subject to change without notice or
obligation.
SERVICE CAUTION
NEVER connect the receiver to a DC power supply
that uses more than the specified voltage. This will
ruin the receiver.
DO NOT expose the receiver to rain, snow or liquids.
DO NOT reverse the polarities of the power supply
when connecting the receiver.
ORDERING PARTS
Be sure to include the following four points when
ordering replacement parts:
1. 10-digit Icom part number
2. Component name
3. Equipment model name and unit name
4. Quantity required
<ORDER EXAMPLE>
1110009630 NJG1108HA8-TE1
8930084870 3384 REAR SHEET IC-R30 CHASSIS
Addresses are provided on the inside back cover for
your convenience.
REPAIR NOTES
1. Make sure that the problem is internal before
disassembling the receiver.
2. DO NOT open the receiver until you have
disconnected it from its power source.
3. DO NOT force any of the variable components.
Turn them slowly and smoothly.
4. DO NOT short any circuits or electronic parts.
An insulated tuning tool MUST be used for all
adjustments.
5. DO NOT keep power ON for a long time when the
receiver is defective.
6. READ the instructions of the test equipment
thoroughly before connecting it to the receiver.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the
United Kingdom, Germany, France, Spain, Russia, Australia, New Zealand, and/or other countries.
FREQUENCY
COVERAGE of A-Band
(MHz)
0. 1 00000~ 3304.999990
0. 1 00000~ 821.999990
851.000000~ 866.999990
896.000000~ 3304.999990
0. 1 00000~ 3304.999990
IC-R30 MAIN UNIT 5 pieces
1 piece
