SECTION 5 PARTS LIST

[VR BOARD]
REF ORDER
NO. NO.
R131 7210003040 VARIABLE
R141 7210003030 VARIABLE
R143 7030003540 S.RESISTOR
J101 6510020710 S.CONNECTOR 52793-1090
EP1 0910051172 PCB
[PHONE BOARD]
REF ORDER
NO. NO.
L121 6200003950 S.COIL
R121 7030006070 S.RESISTOR
R122 7030006070 S.RESISTOR
C121 4030006880 S.CERAMIC
C122 4030006880 S.CERAMIC
C123 4030006880 S.CERAMIC
J101 6510020710 S.CONNECTOR 52793-1090
J121 6510021480 CONNECTOR
EP1 0910051182 PCB

[LOGIC BOARD]

REF ORDER
NO. NO.
IC101 1140008250 S.IC
IC231 1140005880 S.IC
IC351 1110003690 S.IC
IC391 1130009110 S.IC
IC392 1130006440 S.IC
IC401 1130004921 S.IC
Q351 1590000680 S.TRANSISTOR DTC114EUA T106
Q391 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q401 1590001650 S.TRANSISTOR XP4601 (TX)
Q421 1590000720 S.TRANSISTOR DTA144EUA T106
Q511 1510000510 S.TRANSISTOR 2SA1576A T106R
Q512 1590001650 S.TRANSISTOR XP4601 (TX)
D381 1730002320 S.ZENER
D382 1790000970 S.DIODE
D393 1750000550 S.DIODE
D401 1750000550 S.DIODE
D461 1730002530 S.ZENER
X111 6050009460 S.XTAL
X112 6050009870 S.XTAL
L491 6200003950 S.COIL
L492 6200003950 S.COIL
L501 6200002970 S.COIL
L502 6200002970 S.COIL
DESCRIPTION
TP96D26-22F-10KBX2-2240
TP96D00-22F-10KBX2-2240
ERJ3GEYJ 682 V (6.8 kΩ)
B 5271B
DESCRIPTION
HF50ACC 322513-T
ERJ12YJ101H (100 Ω)
ERJ12YJ101H (100 Ω)
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
HLJ2307-01-3070
B 5272B
DESCRIPTION
HD6433837SC58H
X25320S8I-2.7T6
M62354GP 75EC
S-80942ANMP-DD6-T2
TC7S08F (TE85R)
TC74HC04AF (TP1)
MA8051-M (TX)
MA729 (TX)
1SS355 TE-17
1SS355 TE-17
NNCD6.2G-T1
CM200S SMD (32.768KHZ)
CR-567 (9.8304 MHz)
HF50ACC 322513-T
HF50ACC 322513-T
NL 322522T-121J
NL 322522T-121J
[LOGIC BOARD]
REF ORDER
NO. NO.
L503 6200003950 S.COIL
R112 7030003800 S.RESISTOR
R121 7030003440 S.RESISTOR
R122 7030003440 S.RESISTOR
R123 7030003440 S.RESISTOR
R124 7030003440 S.RESISTOR
R125 7030003440 S.RESISTOR
R126 7030003440 S.RESISTOR
R127 7030003360 S.RESISTOR
R128 7030003440 S.RESISTOR
R129 7030003440 S.RESISTOR
R130 7030003440 S.RESISTOR
R131 7030003440 S.RESISTOR
R141 7030003440 S.RESISTOR
R142 7030003440 S.RESISTOR
R143 7030003440 S.RESISTOR
R144 7030003440 S.RESISTOR
R145 7030003440 S.RESISTOR
R146 7030003440 S.RESISTOR
R147 7030003440 S.RESISTOR
R148 7030003440 S.RESISTOR
R149 7030003440 S.RESISTOR
R150 7030003440 S.RESISTOR
R151 7030003440 S.RESISTOR
R152 7030003440 S.RESISTOR
R153 7030003440 S.RESISTOR
R154 7030003440 S.RESISTOR
R155 7030003440 S.RESISTOR
R161 7030003640 S.RESISTOR
R162 7030003640 S.RESISTOR
R163 7030003640 S.RESISTOR
R171 7030003440 S.RESISTOR
R172 7030003440 S.RESISTOR
R173 7030003440 S.RESISTOR
R174 7030003440 S.RESISTOR
R175 7030003440 S.RESISTOR
R176 7030003440 S.RESISTOR
R177 7030003440 S.RESISTOR
R178 7030003440 S.RESISTOR
R179 7030003440 S.RESISTOR
R191 7030003440 S.RESISTOR
R192 7030003440 S.RESISTOR
R193 7030003440 S.RESISTOR
R194 7030003440 S.RESISTOR
R195 7030003440 S.RESISTOR
R196 7030003440 S.RESISTOR
R197 7030003440 S.RESISTOR
R198 7030003680 S.RESISTOR
R201 7030003440 S.RESISTOR
R202 7030003440 S.RESISTOR
R203 7030003440 S.RESISTOR
R204 7030003440 S.RESISTOR
R205 7030003440 S.RESISTOR
R206 7030003440 S.RESISTOR
R208 7030003440 S.RESISTOR
R209 7030003440 S.RESISTOR
R210 7030003440 S.RESISTOR
R211 7030003440 S.RESISTOR
R221 7030003400 S.RESISTOR
R223 7030003560 S.RESISTOR
R224 7030003560 S.RESISTOR
R225 7030003560 S.RESISTOR
R231 7030003680 S.RESISTOR
R251 7030003540 S.RESISTOR
R252 7030003540 S.RESISTOR
R253 7030003540 S.RESISTOR
R254 7030003540 S.RESISTOR
R255 7030003540 S.RESISTOR
R256 7030003540 S.RESISTOR
R257 7030003540 S.RESISTOR
R258 7030003540 S.RESISTOR
R259 7030003540 S.RESISTOR
R260 7030003540 S.RESISTOR
R261 7030003540 S.RESISTOR
5 - 1
DESCRIPTION
HF50ACC 322513-T
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
S.=Surface mount
