SECTION 6
[CHASSIS UNIT]
REF PART
NO. NO.
J1 6510032720 3754 ANT CONNECTOR
SP1 2510002150 C36N07M-7
W1 8900016360 OPC-1190A
EP1 3310005180 GNBA-A13B (031015271EI1000
EP2 8940000120 3754 KEY P.C.B.
MP1 8210033780 3754 REAR PANEL (A) ASSEMBLY
8210033050 3754 REAR PANEL ASSEMBLY
8210033050 3754 REAR PANEL ASSEMBLY
MP2 8930084870 3384 REAR SHEET
MP3 8930030920 1301 SHEET
MP4 8930063280 DOUBLE SIDE TAPE (AP)
MP5 8930060200 HIMELON SHEET (CJ)
MP6 8930095450 3822 SPONGE
MP7 8930099180 3754 ANT PLATE
MP9 8930089520 3484 GPS SPONGE
MP14 8930097260 3754 JACK CAP (KOB)
MP15 8850003250 PLAIN WASHER (AU)
MP16 8810011360 TRUSS B0 2×5 SUS SSBC
MP18 8930069020 O-RING (BG)
MP19 8830000571 STEP NUT (A)-1
MP20 8610016380 KNOB N-451
MP21 8930097250 3754 SD CAP (KOB)
MP22 8930051390 2304 SHAFT
MP23 8310091290 3754 LOCK PLATE
MP24 8930096840 3699 CONTACT RUBBER (TOP)
MP25 8810009181 FLAT BT M2×5 NI-ZC3
MP26 8810009181 FLAT BT M2×5 NI-ZC3
MP27 8810009181 FLAT BT M2×5 NI-ZC3
MP28 8810009181 FLAT BT M2×5 NI-ZC3
MP29 8210033030 3754 FRONT PANEL ASSEMBLY
MP31 8930097240 3754 MAIN SEAL (YG)
MP32 8310091150 3699 WINDOW PLATE
MP33 8930096850 3699 WINDOW SHEET
MP34 8930090100 O-RING (CX) (TOT)
MP35 8930099230 3754 SP HOLDER
MP36 8810009181 FLAT BT M2×5 NI-ZC3
MP37 8950009410 3766 T-KEY (F) (YTP)
MP39 8820001510 3062 SCREW
MP40 8930063690 O-RING (BA) (TOP)
MP41 8930059290 O-RING (AU) (TOP)
MP42 8830003660 STEP NUT (M)
MP44 8810000101 PH M2×4 ZK3
MP46 8930099210 3754 ANT EARTH PLATE
MP47 8930099190 3754 A-EARTH PLATE
MP48 8930099220 3754 B-EARTH PLATE
MP49 8930098420 SPONGE (PK)
MP51 8930093160 SPONGE (NS)
MP52 8930099530 SPONGE (PR)
MP53 8930099540 SPONGE (PS)
MP55 8930059331 SHIELD SPONGE (W)-1
MP56 8930070581 SHIELD SPONGE (BA)-1
MP57 8930070581 SHIELD SPONGE (BA)-1
MP58 8930085111 SHIELD SPONGE (CX)-1
MP59 8930100100 3754 INSULATION SHEET
*: Refer to "BOARD LAYOUTS" for the location.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head BS: Brass NI: Nickel ZU: Zinc SUS: Stainless

MECANICAL PARTS

DESCRIPTION QTY.
[#12]
[#16]
[#20]
Only [#12]
Only [#12]
Only [#12]
Only [#12]
Only [#12]
[LOGIC UNIT] (for #12 and #20)
REF PART
NO. NO.
1 J1* 6510031380 31FXVL-RSM1-GAN-TF-1 (HF)
J2* 6510028170 SDHL-8BNS-K-363-A0-ETB (HF)
1 J3* 6510023480 AYU1-1P-02676-120-TF
J4* 6510032320 50P4.0-JMCS-G-TF (N)
1 J6* 6510031390 15FXVL-RSM1-GAN-TF-1 (HF)
1 DS4 5030004360 TM128160D1CIWUGND
1
S1 2250001070 ED09D21OFD14.0S6.0C20G
1
1 BT1* 3020000390 ML414HIV01E
1
1 EP100 6910027670 AS-G125A2BACAD-AA
1
1 MP1* 8510022450 3754 GPS CASE
1 MP2 8930099300 SHIELD TAPE (AG)
1 MP3 8930099310 SHIELD TAPE (AH)
1
MP4 8930099250 3754 LOGIC PLATE
1 MP5 8210032890 3699 REFLECTOR
1 MP6 8930096860 3699 WHITE SHEET
1 MP7 8930096870 3699 LCD FILTER
1 MP8 8930099240 3754 LCD HOLDER
1 MP9 8930094680 DOUBLE SIDE TAPE (CC)
1 MP10 8930083700 DOUBLE SIDE TAPE (BM)
1 MP11 8930098430 SPONGE (PL)
1 MP12 8930099610 3754 LCD SHEET
1 MP200* 8510022430 3754 DSP CASE
1
1
1
5
6
5
[MAIN UNIT]
1
1
REF PARTS
1
NO. NO.
1
1
J1000* 6510030041 CSS5005-4R11FSZ
1
J1001* 6510021901 BM02B-ASRS-TF (LF) (SN)
2
J1002* 6510030220 50RF-JMCS-G-1B-TF (N) (LF) (SN)
1
J1003* 6510027390 40FHY-RSM1-GAN-TF (LF) (SN)
6
6
S1000* 2260003320 SKRTLAE010
1
S1001* 2260003320 SKRTLAE010
1
S1002* 2260003320 SKRTLAE010
1
S1003* 2260003320 SKRTLAE010
1
1
EP1 3310004220 KY-058-007-01
1
1
MP1000 8950009230 3699 CONTACT SPRING
1
MP1001* 8510022420 3754 PLL CASE
1
MP1002* 8510022420 3754 PLL CASE
2
MP1003* 8510022440 3754 REF CASE
1
MP1004* 8510022460 3754 A-VCO CASE
1
MP1005* 8510022490 3754 G-VCO CASE
1
MP1006 8510022400 3754 S-SHIELD PLATE
1
MP1007 8510022500 3754 MAIN SHIELD PLATE
1
MP1008 8930099320 SHIELD TAPE (AI)
MP1009 8930099320 SHIELD TAPE (AI)
MP1010 8930099290 SHIELD TAPE (AE)
MP1011 8930099340 SHIELD TAPE (AK)
MP1012 8930099330 SHIELD TAPE (AJ)
MP1013 8930099380 3754 MAIN SPONGE
MP1014 8930099390 3754 SPONGE
MP1015 8930099530 SPONGE (PR)
MP1016 8930070581 SHIELD SPONGE (BA)-1
MP1017 8930097440 FERRITE SHEET (BH)
MP1018 8930088330 FERRITE SHEET (AM)
MP1019 8930085101 SHIELD SPONGE (CW)-1
MP1020 8930100120 FERRITE SHEET (BM)
MP1021 8930058510 INSULATION SHEET (HC)
[AF UNIT]
REF PART
NO. NO.
J1* 6510027390 40FHY-RSM1-GAN-TF (LF) (SN)
J2 6450002530 HSJ4456-010320
W1 7030014230 RJ20S0OHM
W2 8900014871 OPC-1332A-1 (P0.5N40L100)
MP1 8930099200 3754 AF PLATE
MP2 8930100110 SPONGE (PU)
6-1
DESCRIPTION QTY.
DESCRIPTION QTY.
Only [#12]
Only [#12]
Only [#12]
Only [#12]
Only [#12]
Only [#12]
DESCRIPTION QTY.
Only [#12]
