51
8.6 Keep the device and its accessories properly for operation next time.
8.7 Recording Paper Loading.
Recording paper
Rubber roller
Printer
• The device adopts high-speed thermal recording paper with the specification of
50mm(W)×20m(L).
• Open the cover of paper carriage, take out the paper roll and install it into record-
ing paper then load them at the proper position inside the carriage.
• Close the cover of paper carriage. It's recommended to leave 2cm paper outside.
Chapter 9
INSTRUCTION OF RECORDING PAPER
9.1 When recording, the device will stop paper trace in case of paper lack, and the
LCD screen will display as the figure below to prompt paper lack.
ENGLISH
Paper Axis
Paper cabinet
Recording paper loading sketch map
