X-Micro WLAN 11g User Manual page 66

5.10.1. To Configure Agent Information, SNMP Trap Host IP
Addresses and Community Names on Your Router:
5.10.1.1. On the Advanced navigation bar, click SNMP.
The SNMP page appears, seen in FIGURE 5-14:
Enter the following Agent information:
Paramet
Name
Contact
Location
FIGURE 5-14: SNMP Page
er
Specifies an administratively-assigned name
for this managed node, like SOHO Router.
It is a string of the maximum 31 alphanumeric
characters.
Specifies the contact person of this managed
node, plus phone number, Email address, etc.
It is a string of the maximum of 255
alphanumeric characters.
Specifies the physical location of this
managed node, for example, city, address
and specific office location.
It is a string of the maximum of 255
alphanumeric characters.
66
Description
