4.8 Log

On the Log page, you can set up Access Log and view log files that
record the access activity of LAN and WAN client PCs, including
Session Event Log, Block Event Log, Intrusion Event Log and
Wireless Event Log.
What do you want to do?
Set up Access Log on Your Router
View Session Event Log
View Block Event Log
View Intrusion Event Log
View Wireless Event Log
4.8.1. To Set up Access Log on Your Router:
4.8.1.1. Click Log on the navigation bar.
The Log page appears, seen in FIGURE 4-20:
4.8.1.2. Select Enable.
4.8.1.3. Click Apply, or click Cancel to undo your changes.
4.8.2. To View Session Event Log:
4.8.2.1. Click Session Event Log on the Log page.
FIGURE 4-20: Log Page
