Chapter 2 Features

Chapter 2 Features
The S5U13L02P00C100 Evaluation Board includes the following features:
• 208-pin QFP22 S1D13L02 LCD controller
• Headers for connection to the S5U13U00P00C100 USB Adapter board
• Header with all S1D13L02 Host Bus Interface signals (optional)
Note
These headers are not mounted. There are allocated spaces for the headers.
• Headers for connecting to LCD panels
• Header for S1D13L02 GPIO pins (optional)
Note
These headers are not mounted. There are allocated spaces for the headers.
• On-board 4MHz oscillator
• 3.3V input power
• On-board voltage regulator with 1.5V output
• On-board voltage regulator with adjustable 38V/60mA max, to provide power for LED back-light of LDC
panels.
