3. Slide the burner slightly toward the front of the heater.
4. Rotate the burner away from the heater.
5. Slide the burner out from the heater. Replace the burner in reverse order.
22.0)

CONVERSION INSTRUCTIONS

a) Remove the Injector from the Injector Fitting (see Section 21.3) and replace it with the alternative Injector
supplied with conversion kit. Check that the size reference marked on the Injector agrees with that listed in the
Specifications table Section 5.0) for the appliance model in question.
b) Remove the pressure governor cap from the integral pressure governor of the Control Valve and screw the
adjuster (both adjuster for 2-stage heaters) clockwise to increase the gas pressure, check supply and manifold
pressure in accordance with Section 15.1) Replace the pressure governor cap.
c) Affix the gas adjustment label supplied with conversion kit onto the Data Label, adjacent to the headings
"Adjusted For" and "Setting Pressure", to cover the original gas adjustment label.
d) Carry out checks in accordance with Section 15.0) of this manual to ensure correct supply pressure relative to
the gas type being used.
23.0)

INSTALLATION DATA

Date of
Installation:
Heater Serial Number:
Heater Model: WB10CE
Form 44201360
Oct 2019
Number of
Heaters in System:
N=Natural Gas
—
L=Propane Gas
