TECSYSTEM VRT200 Instruction Manual page 6

TECHNICAL SPECIFICATIONS
TEST AND PERFORMANCE
Ambient operating temperature from –20°C to +60°C
Humidity 90% non-condensing
Housing NORYL 94 _V0
Absorption 5VA (max)
Protection treatment of the electronic part
Frontal film polycarbonate IP65
DISPLAY AND DATA MANAGEMENT
LED's alarm: undercurrent, overcurrent
LED's running: remote, local
LED's prg setting, cal.
Initial AUTO-TUNING to set up motors' operation
Front button to START/STOP motors locally
Front alarm RESET button
Access to programming through front button
Intellifan function
IMPORTANT WARNING
Before carrying out the isolation test of the electrical panel the control unit is installed on, disconnect M1-M2
outputs and the power supply, to prevent it from being seriously damaged.
