TECHNICAL SPECIFICATIONS

POWER SUPPLY
Supply rated values
INPUTS
2 inputs enabling remote control ENABLE: COM-EN1-EN2
Connections on removable terminal strips
OUTPUTS
1 fault sensor or operating failure (FAULT) relay SPDT
Output relay with 5A-250Vac-res COS
2 outputs M1-M2: 85-250Vca 5A max 50/60Hz. SPST
DIMENSIONS
100x100 mm– din43700-depth 131mm (terminal block included)
TEST AND PERFORMANCE
Construction in compliance with CE regulations
Protection from electrical interference EN 61000-4-4
Dielectric strength 1500 Vac for 1 minute: supply - relay fault, supply - remote.
Ф
=1 contacts.
VRT200
VRT200
85-250 Vca
(10 A max) 50/60 Hz
●
●
●
●
●
Hole 92 x 92 mm
●
●
●
5
