2 BBL Hybrid Brewhouse
2 Vessel
Assembly, Operation, & Maintenance
Congratulations on your purchase, and thank you for selecting the 2 BBL
Hybrid™ Brewhouse from Blichmann Engineering™. We are confident that it
will provide you years of service and many gallons of outstanding beer.
PLEASE READ AND THOROUGHLY UNDERSTAND THIS MANUAL PRIOR TO USE
WARNING: Sections labeled "Warning" can lead to serious injury or death if not followed. Please thoroughly read these sections and understand them
completely before use. If you do not understand them or have any questions, contact your retailer or our website at
www.blichmannengineering.com before use.
CAUTION: Sections labeled "Caution" can lead to equipment damage or unsatisfactory performance of the equipment. Please read these sections
thoroughly. If you have any questions, contact your retailer or our website at www.BlichmannEngineering.com before use.
IMPORTANT: Sections labeled "Important" should specifically be followed to ensure satisfactory results with the product.
IMPORTANT: Power demand for the brewhouse is 32A at 208V (three phase) or 52A at 240V (single phase). Select a main breaker setting for 20% above the appropriate
amperage to avoid nuisance tripping or as directed by your local codes.
Item Number
BEPS-MLT-2BBL
BE-001346-02
BEPS-BK-HLT-2BBL
BEPS-SanitaryHeater-2
BEPS-SanitaryHose-1in-10
BEPS-SanitaryHose-1in-5
BE-000633-00
BE-000868-00
BE-000957-00
BE-000859-00
BE-000866-00
BE-000861-00
2 BBL Hybrid™ 2 Vessel Brewhouse V2
For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts
™
IMPORTANT INFORMATION
FOR IMPORTANT SAFETY INFORMATION!
What' s In the Box?
Description
2 BBL Mash Tun
2 BBL False Bottom Assembly
2 BBL Boil Kettle
2 BBL Sanitary Heater Assembly
Low Level Float Switch
10 foot - 1 Inch ID Hose
5 foot - 1 Inch ID Hose
1.5 Inch Tri-Clamp
1.5 Inch Tri-Clamp Gasket
CIP Spear - 1.5 TC
2.5 Inch TC Cap
2.5 Inch Tri-Clamp Gasket
2.5 Inch Tri-Clamp
© Blichmann Engineering, LLC 2019
Quantity Item Number
1 BE-000863-00
1 BE-001356-00
1 BE-001084-00
2 BE-001186-00
1 BEPS-CHILLER-2.0SQM
1 BE-001345-00
2 BEPS-ControlKit-2Ves-2b
20 BE-001612-00
20
1
2
4
4
Description
1.5 Inch Tri-Clamp Elbow
1.5 Inch Multi Position Valve
1.5 Inch Tri-Clamp CIP Spray Ball
1.5 Inch Sanitary Pipe, 6 Inch Length
Heat Exchanger
2 BBL Stand Pipe
Control Panel
PT 100 RTD Probe
1" Diaphragm Valve
1.5" Tri-Clamp Cap
Quantity
4
3
1
1
1
2
1
2
1
2
1
