7 BBL Insulated Hybrid Brewhouse
Assembly, Operation, & Maintenance
Congratulations on your purchase, and thank you for selecting the 7 BBL Hybrid
Brewhouse from Blichmann Engineering™. We are confident that it will provide you
years of service and many gallons of outstanding beer. This manual will familiarize
you with the use, assembly, and the sanitation procedures for the product.
PLEASE READ AND THOROUGHLY UNDERSTAND THIS MANUAL PRIOR TO USE
WARNING:
Sections labeled "Warning" can lead to serious injury or death if not followed. Please thoroughly read these sections
and understand them completely before use. If you do not understand them or have any questions, contact your
retailer or Blichmann Engineering (www.BlichmannEngineering.com) before use.
CAUTION:
Sections labeled "Caution" can lead to equipment damage or unsatisfactory performance of the equipment. Please
read these sections thoroughly. If you have any questions, contact your retailer or Blichmann Engineering
(www.BlichmannEngineering.com) before use.
IMPORTANT:
Sections labeled "Important" should specifically be followed to ensure satisfactory results with the product.
IMPORTANT: Power demand for the brewhouse is 215A at 208V (three phase), 100A at 480V (three phase) or 310A at 240V (single phase).
Select a main breaker setting for 20% above the appropriate amperage to avoid nuisance tripping or as directed by your local codes.
Item Number
Description
BEPS-BK-7BBL
7 BBL Boil Kettle
BEPS-HLT-7BBL
7 BBL Hot Liquor Tank
BEPS-MLT-7BBL
7 BBL Mash Tun with Mash Rake and Motor
Control Panel
Sanitary Heater Set of 3
BE-000861-00
2.5" Tri Clamp
BEPS-Pump-1HP
1HP Brewery Pump
BEPS-CHILLER-2.0SQM
BEPS-HoseKit-5
5 Hose Assembly Kit
BE-000957-00
CIP Spear 1.5" Tri Clamp
BE-000859-00
Cap 2.5" Sanitary
7 BBL Insulated Hybrid Brewhouse V1
For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts
IMPORTANT INFORMATION
FOR IMPORTANT SAFETY INFORMATION!
What' s In the Box?
Heat Exchanger
© Blichmann Engineering, LLC 2018
Quantity
Item Number
1
BE-000868-00
1
BE-000633-00
1
BE-000863-00
1
BE-001356-00
2
BE-001084-00
3
BE-001186-00
2
BE-000630-00
1
BE-001479-00
1
BE-000866-00
1
BE-001482-00
3
BE-001478-00
Description
Clamp Gasket 1.5"
1.5" Tri Clamp
Tri Clamp Elbow 1.5"
1.5" Multi Position Valve Tri Clamp
CIP Spray Ball
1.5" Sanitary Pipe 6"
Cap 1" & 1.5" Sanitary
6" Gasket
Clamp Gasket 2.5"
6" Tri Clamp Cap
6" Tri Clamp
Quantity
17
17
6
5
1
1
2
1
3
1
1
1
Advertisement
Related Manuals for Blichmann Engineering 7 BBL
Summary of Contents for Blichmann Engineering 7 BBL
- Page 1 Blichmann Engineering (www.BlichmannEngineering.com) before use. CAUTION: Sections labeled “Caution” can lead to equipment damage or unsatisfactory performance of the equipment. Please read these sections thoroughly. If you have any questions, contact your retailer or Blichmann Engineering (www.BlichmannEngineering.com) before use. IMPORTANT: Sections labeled “Important”...
- Page 2 It is recommended that you consult your local codes and consult with a professional prior to purchasing or installing your ventilation equipment. For recommendations on professional ventilations contact a Blichmann Engineering Pro Brewing representative. Total power for the Boil Kettle is 36 KW.
-
Page 3: Control Panel
CONTROL PANEL 7 BBL Insulated Hybrid Brewhouse V1 © Blichmann Engineering, LLC 2018 For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts... -
Page 4: Three Phase
Power demand for the brewhouse is 215A at 208V (three phase) or 100A at 480V (three phase). Select a main breaker setting for 20% above the appropriate amperage to avoid nuisance tripping or as directed by your local codes. 7 BBL Insulated Hybrid Brewhouse V1 © Blichmann Engineering, LLC 2018... - Page 5 IMPORTANT: Always consult your local codes to determine what type of cable is acceptable, what gauge is required, and maximum lengths of flexible cable allowed. 7 BBL Insulated Hybrid Brewhouse V1 © Blichmann Engineering, LLC 2018 For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts...
- Page 6 VFD terminal block. Connect wiring from 104T1 to U1, 104T2 to V1, 104T3 to W1 for power and GND to the grounding screw for ground. 7 BBL Insulated Hybrid Brewhouse V1 © Blichmann Engineering, LLC 2018 For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts...
- Page 7 Figure 1 Nuts and Bolts Divot Two Piece Impeller Shaft Step 2: Place the shaft into the kettle as shown in Figure 2. Figure 2 7 BBL Insulated Hybrid Brewhouse V1 © Blichmann Engineering, LLC 2018 For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts...
- Page 8 Align the motor shaft with the gear box adapter shown in Figure 6. Gearbox Adapter Figure 6 Figure 5 Step 7: Using the nuts and bolts provided, secure the gear box to the motor. 7 BBL Insulated Hybrid Brewhouse V1 © Blichmann Engineering, LLC 2018 For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts...
- Page 9 A. Limited Warranty Blichmann Engineering warrants to the original purchaser that this product will be free from manufacturing defects in material and workmanship for a period of one (1) year from the date of purchase by the customer. Proof of purchase is required. Blichmann Engineering’s obligation to repair or replace defective materials or workmanship is the sole obligation of Blichmann Engineering under this limited warranty.
