Additional switch
Hide thumbs Also See for 2N Analog Force:

Advertisement

Remove 4 screws holding 2 horizontal pillars, then remove the pillars and button
3.
board.
Replace 2 distance pillars from the lower side of intercom by the 2 longer
4.
distances delivered with departure switch.
Insert departure switch and fix it with the two shorter distance pillars delivered
5.
with the switch.
Make a wire connection to the switch.
6.
2N TELEKOMUNIKACE a.s., www.2n.cz
6/12
