2. Installation

Caution
Before installing the module, make sure that the current and voltage
limits of the module will not be exceeded in your application (refer to
the Technical Parameters chapter). Never use this module for mains
voltage switching!
of the additional switch.
Remove 4 screws from the top side of intercom, then remove the top metal
1.
plate.
Remove keypad.
2.
2N TELEKOMUNIKACE a.s., www.2n.cz
All wiring has to be done only after proper installation
5/12
