Example 2 – dep. switch operation for unlimited time
Dep. switch closure is set to SWITCH 1, dep. switch opening to SWITCH 2. The dep.
switch will close when it has received the password for SWITCH 1 and will remain
closed until the communicator has received the password for SWITCH 2 and until the
switching time of SWITCH 2 elapses (parameter 823 , it is recommended to set this
parameter as low as possible, which is 1s).
Example 3 – dep. switch closure for the duration of the call
Closure and opening is set to SPEAK. The dep. switch will close when the line is picked
up and open when the line is hung up. For the duration of the call the dep. switch will
be closed.
