LED LINK
This is directly addressed by the Ethernet-controller and signalizes that the UNIGATE® IC is con-
nected to an operable network (LINK-pulses are being received).
14.2.2

Connectors of the basis board

14.2.2.1

Connector to the external device (RS-interface)

The connection cable to the external device must be plugged in at the connector accessible on
the underside of the device.
Pin assignment P7 (9-pin Sub-D, plug)
Pin No. Name
1
2 Rx/RS485- / RS422- (Tx)
3 Tx/RS485+ / RS422+ (Tx)
4 Tx / Diag
5 GND RS
6 RS422- (Rx)
7 RS422+ (Rx)
8 Not connected
9 Rx / Diag
Attention:
In case the RS-interface is NOT potentially divided, "GND" and "supply
0V" are connected internally.
Pin assignment P2 (2-pin screw-type/plug connector)
Pin No. Name
1 10.8...30 V / DC
2 0 V / DC
14.2.2.2

Ethernet connector

The connector for the connection to Ethernet (RJ45) is located on the upper side of the device.
Pin No. Name
1 TX+
2 TX-
3 RX+
4 n. c.
5 n. c.
6 RX-
7 n. c.
8 n. c.
14.2.2.3

Power supply of the basis board

The device must be powered with 10.8-30 VDC.
Please note that the devices of the series UNIGATE® with 9-pin D-SUB connector, the power
supply is routed via the separate 2-pin screw-type/plug connector.
Please pay attention to the fact that devices of the series UNIGATE® cannot be operated with
AC voltage.
40
Function
Receive signal customer's device
Transmit signal customer's device
Transmit signal Debug interface
Ground connection, reference for PIN 2+3+6+7
Not connected
Receive signal Debug interface
Function
10.8...30 V supply voltage
0 V supply voltage
Function
Transmission line+
Transmission line -
Receive line+
Not connected
Not connected
Receive line-
Not connected
Not connected
