Parts and Components

Your Drop System is designed and assembled entirely by DJI
Shop Canada staff in-house. All major components, with the
exception of a few parts, are 3D printed and assembled by
hand to ensure a sturdy and reliable build. A breakdown of the
parts and components are indicated in the illustrations below.
1
7
8
1. Manual Pin Release Button
2. Security Lock
3. Main Clip Assembly
4. Servo and Servo Protector Box
Your unit may differ slightly from the depicted
illustrations in this user guide
5. Servo Arm
6. Payload Pin
7. Electronics Box and Cover
8. Navigation Light Sensor Clip
2
6
3
4
5
