Sharp JW Series Connection Manual page 65

A. When using the COM port conversion adapter (CA3-ADPCOM-01), the terminal block conversion adapter
(CA3-ADPTRM-01) by Pro-face and your own cable
• 1:1 Connection
Display
CA3-ADPCOM-01
CA3-ADPTRM-01
• 1:n Connection
Display
CA3-ADPCOM-01
CA3-ADPTRM-01
B. When your own cable is used
• 1:1 Connection
Display
GP-Pro EX Device/PLC Connection Manual
Signal name
RDA
RDB
SDA
SDB
SG
FG
Shield
Signal name
RDA
RDB
SDA
SDB
SG
FG
D-Sub 9 pin (socket)
Pin Signal name
1 RDA
2 RDB
SDA
3
7 SDB
5 SG
ERA
4
8
CSA
9
ERB
6
CSB
Shell FG
JW Series Computer Link SIO Driver
Shield
Your own cable
External Device
D-Sub 15 pin (plug)
Pin Signal name
3 SD(+)
11 SD(-)
9 RD(+)
10 RD(-)
1 FG
Your own cable
D-Sub 15 pin (plug)
Shield
65
External Device
D-Sub 15 pin (plug)
Pin Signal name
3 SD(+)
11 SD(-)
9 RD(+)
10 RD(-)
1 FG
External Device
D-Sub 15 pin (plug)
Shield
Pin Signal name
3
11
9
10
1
External Device
Pin Signal name
3 SD(+)
11 SD(-)
9 RD(+)
10 RD(-)
1 FG
SD(+)
SD(-)
RD(+)
RD(-)
FG
