Settings of External Device
Set the bit of system memory in the External Device to ON or OFF. Please refer to the manual of the External
Device for more details.
Restart the power of the External Device after setting to enable the setting.
Setting for #0236
Setting Area
#0236
• Description for Bit
Bit in System Area
D0
D1
D2
D3
D4
D5
D6
D7
Setting for #0237
Setting Area
#0237
Termination Resistance Switch
Insert the termination resistance at the end. Connecting the 6th and 13th pins in the port on the External Device
allows the termination resistance to be inserted.
GP-Pro EX Device/PLC Connection Manual
Setting
Value
Communication setting. Enter in hex number.
30(H)
Description for each bit is shown below.
Setting
Value
OFF
OFF Transfer Speed: 19200 bps
OFF
OFF
Parity: Even
ON
ON Stop Bit: 2 bits
OFF Always OFF
OFF Always OFF
Setting
Value
1(o) Station No. setting. Enter in octal number.
JW Series Computer Link SIO Driver
Setup Description
Setup Description
Setup Description
