Sharp JW Series Connection Manual page 66

• 1:n Connection
D-Sub 9 pin (socket)
Pin
1
2
Display
3
7
5
4
8
9
6
Shell
C. When using the online adapter (CA4-ADPONL-01), the terminal block conversion adapter (CA3-ADPTRM-
01) by Pro-face and your own cable
• 1:1 Connection
Display
CA4-ADPONL-01
CA3-ADPTRM-01
• 1:n Connection
Display
CA4-ADPONL-01
CA3-ADPTRM-01
GP-Pro EX Device/PLC Connection Manual
Shield
Signal name
RDA
RDB
SDA
SDB
SG
ERA
CSA
ERB
CSB
FG
Signal name
RDA
RDB
SDA
SDB
SG
FG
Shield
Signal name
RDA
RDB
SDA
SDB
SG
FG
JW Series Computer Link SIO Driver
External Device
D-Sub 15 pin (plug)
Pin Signal name
3 SD(+)
11 SD(-)
9 RD(+)
10 RD(-)
1 FG
Shield
Your own cable
External Device
D-Sub 15 pin (plug)
Pin Signal name
3 SD(+)
11 SD(-)
9 RD(+)
10 RD(-)
1 FG
Your own cable
66
External Device
D-Sub 15 pin (plug)
Shield
Pin Signal name
3 SD(+)
11 SD(-)
9 RD(+)
10 RD(-)
1 FG
External Device
D-Sub 15 pin (plug)
Pin Signal name
3 SD(+)
11 SD(-)
9 RD(+)
10 RD(-)
1 FG
External Device
Shield
D-Sub 15 pin (plug)
Pin
3
11
9
10
1
Signal name
SD(+)
SD(-)
RD(+)
RD(-)
FG
